KT-C Series Travel Head Cutting Machine

Shoe Cutting Machine

Leather die Cutting Press Machine/ Hydraulic Die Cutting Machine/Shoe Making Machine

Rotating Head Cutting Machine/Travelling Head Cutting Press for Leather/PVC Desk Pad/Shoes Insoles/Ball Panels

Hydraulic Die Cutting Press for Cutting Reinforcing Mesh Cutting Wheels

Features of Cutting Machine

1. This type of cutting machines are widely used for cutting applications of nonmetal materials, especially hard materials. Such products as insoles, football, volleyball or tennis panels, glass fibre cutting wheels, car interior decoration materials and medical supplies are made by this machine.

2. Servo motor makes accurate feeding possible and controls horizontal movement of the cutting head. Multilayers of materials can be clamped by the cylinder for step feeding. Other feeding methods such as conveyor belt type are also available on request.

3. The feeding length can be easily set by the human-computer interface or PLC control panel (Optional).

4. Special hydraulic system makes low noise possible and saves oil.

5. High quality and imported oil pump and other parts are available on request.

6. Because the machine is well controlled by PLC control panel, only one worker is required for the whole operation. Therefore, the production efficiency of this kind of die cutting machine is 3 to 5 times that of a normal cutting machine and the power can be saved by about 2/3.

7. Maximum cutting force of the die cutting machine caters to customer’s specific application requirements.

Option of Shoe Cutting Machine

• Rotating head

• Machine Color
• Servo Motor
• Imported oil pump

• Roll Unwinding Frame
• Bed Size
• Feeding Method
• Parts Brands

Technical Information(Customizable)--Shoe Cutting Machine

Rotating Head Cutting Machine/Travelling Head Cutting Press for Leather/PVC Desk Pad/Shoes Insoles/Ball Panels

Shoe Cutting Machine with Conveyor Belt Type Auto Feeding Method

Inner Package: Protective Film, etc

Outside Package: Plywood Case

• Cutting machines well packed with protective film and loaded in plywood case or export container;
• English version operation manual and technical data;
• One-Year-Period wear parts;
• Tool kit
