Product Description

Underground borehole Wide-Angle Panoramic Probe 2000m deep well inspection camera

Brief introduction of PIW-P2000 deep well inspection camera:

1. PIW-P2000 is a new design Panoramic Probe camera specializes in well/borehole inspection.

2. It provides clear video inspection services for well depth from 1000m-2000m ranges.

Specifications of PIW-P2000 deep well inspection camera:

Main Control Box
Aluminum Alloy Main Machine, 220V
Winch
Electric Winch.
Display Screen
12” Monitor
Video System
SD Card
Panoramic Probe
HD, Low Light 130o Wide-Angle Camera
Depth Counter
Accurate to 0.05m
Cable
4-core Bearing, 1000-2000m
Centralizer
High Elasticity Stainless Steel
Tool Box
Connecting Cables and Accessories
Detailed Image

Control Box

* Aluminum Control Box(ABS is optional): aluminum panel, size: 300 * 400 * 260mm
* Voltage Input: 220V
* Depth Interface: connect the depth sensor
* Probe Interface: connect the probe, transmit video and power
* Data Interface: can create well number/position automatically, and calibrate depth automatically.
* Video System: standard 8G, SD card recording system, max. support 32G
* Depth Return to Zero: return depth to zero before logging to ensure accuracy.
* Display Monitor: 7 inch (12 inch optional), high light LED monitor, visual outdoor.

Panoramic Camera

* Panorama Camera: Φ75mm，(Φ55mm/Φ85mm）
* Camera Material: split galvanized iron
* Camera Lens: anti-reflective and anti-wear resin lens
* Camera pixels: CCD camera, 700TVL
* Lens Angle: 130o wide angle
* Camera Light: equipped with 9-15 high bright LED with cold light source
* Probe Pressure-resistance: 20MPA, 2500m max. Pressure-resistant depth.

Winch

* Electric Winch: 220V. You can control the speed and probe lifting manually by control box.
* Motor: permanent magnet DC motor,
* Winch: iron stamping gear plate motor
* Split Docking Probe: easy to exchange probes with different size.

Depth-Counting Cable

* Material: modified polypropylene
* Pulling Force: 280KG
* Outer Diameter: 7.2mm
* Temperature: 80°

Down the Hole Pulley

* Pulley: with meter-counter function. It needs to connect with control box with data cable.
* Depth Counter: accurate to 0.05m, adjustable
* Pulse: 500

Monitor

* Dimension: 12”
* Aspect Ratio: 4: 3
* Contrast: 500: 1
* Brightness: 1000cd/m2
* Resolution: 1024 x 768
* Power: DC 12V
* Color System: PAL / NTSC / SECAM

Optional

Hole Video Imaging Detection Report Software

Reading hole problems and giving out report. It is mainly used to playback, preview, screenshot, interpretating the hole conditions. It can also edit segment information of variable hole and generate pipe longitudinal section figure and output test report automatically.

Packing & Delivery

Safe Packing.
Wooden carton with foam.

    Fast delievery.
    DHL, FedEx and UPS.

Related Products
Our Company
Our Service

1.Professional technical support pre-sale, sale and after-sale.
2.Your problems can get feedback in 8 hours and be solved in 24 hours.
3.Machine can be customized as per your requirement.
4.One year quality warranty.
5.Training: operation manual and DVD operation video, overseas installation is also available.
6.Spare parts are available in our factory at cost price for former customers.
