Small Cheap Robot All Terrain Vehicles Rubber Track

Small cheap robot all terrain vehicles rubber track

Tins-3 robot platform is mainly used for secondary development of robot products.

The platform is equipped with various interfaces for installation, such as,  mechanical arm, cameras, draft gear, etc.

1. Small size 300*290*120mm, light weight 6.5kg, big loading capacity 60kg, especially good to work in small areas.
2. Rubber Track: with good ground adhesion, all-terrain chassis.
3. Patent Suspension System: 1) up and down fluctuation suspension system. 2) center of gravity shock absorption suspension. Our unique design.
4. Guiding Wheel: self-tension, automatic adjust, ensuring timely tension and running.
5. Separate Self-control Circuit and Extending Circuit: 1) mechanical extending with detachable front/rear/and upper cover plate, greatly reducing customizing risk. 2) Electrical extending with 5V3A, 12V3A circuit for 5/6/13 extending circuit.
6. Power and Control: 1) battery and wireless control: support 13-Way Servo Control Signal and 4-Way active control signal. 2) wire mode: support 4-Way active control signal, with one XY lever and 6-way servo control lever.
7. Optional Modular: no-map navigation, position tracking lock, etc.

Zhengzhou Defy Mechanical & Electrical Equipment Co,. Ltd.

is a leading robot manufacturer in China, offering robots and mobile solutions for robotic products. With great development, we have established one-stop solutions for global clients, with our own R&D department, Q&C department, production department, sales department, and after-sales department.

Our spirit is "Unity ,Diligence ,Integrity ,Innovation"

Our mission is "Invent and Create high quality robot and automatic machines ,letting them work and solve difficulties for human beings ."

Our aim is "100% Customer Satisfaction"

Hot



Our Service



1. Warranty: one year for main machine, excluding easily wear parts. During this period, in case of damage or breakdown, we will repair to replace spare part freely, while the buyer should bear overseas freight.

2. Spare Parts: Most of our spare parts are compatible with international standard. While, we offer spare parts all year round at cost price for our former clients.

3. Operation and Maintenance: We will offer you detailed operation manual, ensuring you can use it perfectly.

4. Online Service: Your question will be answer within 24 hours during working days, 48 hours during holiday.



If you are intereted in our chassis robot platform,please do not Hesitate to contact us.



Please    Send Inquiry Now
