Spraying 6-axis Industrial Robot ZXP-E2013i, Playload 13kg, Arm Length 2000mm,simple Operation Widely Used in Spraying Industry
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
2001
Annual Export Value:
Above US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Welding Application 6-axis Industrial Robot ZXP-D1606i, Load 6kg, Arm Length 1600mm, Flexible Movement and Easy OperationNegotiableMOQ: 1 -
6-axis Industrial Robot ZXP-R2260i Playload 60kg and Length of 2202.5mm Can Carry Out Sheet Metal Handling ,sheet Metal BendingNegotiableMOQ: 1
-
Universal 6-axis Industrial Robot ZXP-S3030i Playload 30kg Length 3000mm, Handling, Palletizing, Assembling, Injection MoldingNegotiableMOQ: 1
-
Welding 6-axis Industrial Robot ZXP-D1506i, Load 6kg, Arm Length 1600mm, Waterproof and Dustproof, Flexible Action, Easy WiringNegotiableMOQ: 1
-
Universal 6-axis Industrial Robot ZXP-S2520a, Load 200kg, Arm Length 2570mm, Loading and Unloading, Handling, Palletizing RobotNegotiableMOQ: 1
Product Description
6-axis robotic arm ZXP-E2013i
payload of 13kg/ reach of 2200mm.
ZXP-E2013i is a six-axis robot developed by AE Robotics for the spray application industry. It has an ultra-long arm span of 2000mm and a maximum load of 13kg. The robot is compact, highly flexible and technologically advanced and can be used in a wide range of spray applications. High protection level - wrist IP65, body IP68, dustproof, waterproof and explosion-proof. High accuracy—repeated positioning accuracy ±0.5mm.
Specification
type | ZXP-E2013i |
Axis | 6 |
Payload | 13kgs |
Net Weight | 400kgs |
arm reach | 2000mm |
Repeatability | +/-0.5mm |
Protection class | IP68 |
battery capacity | 6.3KVA |
Application | Spraying |
Axis | Working range | Working speed |
J1 | ±162.5° | 105°/s |
J2 | ±124° | 105°/s |
J3 | -57°~+237° | 123°/s |
J4 | ±180° | 473°/s |
J5 | ±180° | 519°/s |
J6 | ±360° | 613°/s |
Packing & Delivery
Packing material: shockproof cotton, insulation paper pad, carton, wooden case
Company Profile
AE Robotics Co,. Ltd
AE Robotics Co., Ltd was founded in January 2015. We focus on discrete industrial automation and industrial process automation, and can design, develop, test install, debug industrial robots, their units and related accessories, including accessories, devices transmission, positioning devices. and control system.
We can provide cobot robot, industrial robot, robot parts, CNC controller, robot integration, etc.
We expect our professional technical services to provide customers with the best return on investment.
