Product Description

6-axis robotic arm ZXP-D1506i
payload of 6kg / reach of 1600mm.

ZXP-D1506i is a six-axis robot developed by AE Robotics for the welding application industry. The robot is compact, small in size, light in weight, with a maximum load of 6KG and an arm span of 1600mm. The wrist adopts a hollow structure, which is more convenient for wiring and more flexible in movement. The protection level is higher than the wrist IP54, the body IP50, dustproof and waterproof. High accuracy - repeat positioning accuracy ±0.05mm.

Specification

type	ZXP-D1506i
Axis	6
Payload	6kgs
Net Weight	166kgs
arm reach	1600mm
Repeatability	+/-0.2mm
Protection class	IP50
battery capacity	6KVA
Application	Welding

Axis	Working range	Working speed
J1	±160°	163°/s
J2	-100°/+75°	148°/s
J3	±82°	223°/s
J4	±150°	168°/s
J5	±110°	270°/s
J6	±360°	703°/s

Packing & Delivery

Packing material: shockproof cotton, insulation paper pad, carton, wooden case
