W0204 15" 3 HP Thickness Planer with Helical Cutter Head
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
- Double arbor muliti rip saw heavy duty woodworking auto multiple rip saw
- LIVTER W0106F 6 Inch 150 Cast Iron Straight Knife Spiral Knife Wood Jointer Machine
- LIVTER Woodworking Machinery W0106F Jointer Planer Spiral
- W0301 12\" 300Mm Jointer Thicknesser Combination
- LIVTER W0301 12\" 300Mm Jointer Thicknesser Combination
- LIVTER 12\" Wood Jointer Woodworking Machine Woodworking Surface
Product Description
Products Description
W0204 15" 3 HP Thickness Planer with Helical Cutter Head
Model | W0204 15" Planing Straight Knife | WO204R 15" Planer Fillet Spiral Knife | W0204S 15" Planing Right Angle Spiral Knife | |
Motor | Induction motor, 220V, single phase, output 2200W, input 2700W | Induction motor, 220V, single-phase output 2200W, input 2700W | Induction motor, 220V, single phase, output 2200W, input 2700W | |
Parameter | Maximum planing width: 381mm | Maximum planing width: 381mm | Maximum planing width: 381mm | |
Maximum planing depth: 4mm | Maximum planing depth: 4mm | Maximum planing depth: 4mm | ||
Shortest planer length: 160mm | Shortest planer length: 160mm | Shortest planer length: 160mm | ||
Maximum planing thickness: 204mm | Maximum planing thickness: 204mm | Maximum planing thickness: 204mm | ||
Tool shaft | Spindle speed: 5000RPM | Spindle speed: 5000RPM | Spindle speed: 5000RPM | |
Number of blades: 3 pieces (high speed steel) | Number of blades: 80 pieces in 5 slots (imported) | Number of blades: 96 pieces in 4 slots (imported) | ||
Blade size: 385*25*3mm | Blade size: 15*15*2.5mm | Blade size: 14*14*2mm | ||
Cutting diameter: 75mm | Cutting diameter: 75mm | Cutting diameter: 75mm | ||
Workbench | Table size: 453*381mm | Table size: 453*381mm | Table size: 453*381mm | |
Cast iron extension wing size: 406*306mm | Cast iron extension wing size: 406*306mm | Cast iron extension wing size: 406*306mm | ||
Appendix | Pedal-type swivel casters, switch bracket, Taiwan magnetic starter, 100mm oblique dust collection port, two-speed feed gearbox, rubber discharge rod | Pedal type movable casters, switch bracket, Taiwan magnetic starter, 100mm oblique dust collection port, two-speed feed gearbox, rubber discharge stick | Pedal type movable casters, switch bracket, Taiwan magnetic starter, 100mm oblique dust collection port, two-speed feed gearbox, rubber discharge stick | |
Package dimensions | 835*635*1220mm | 835x635x1220mm | 835*635*1220mm | |
Weight | Net weight 250kg/gross weight 290kg | Net weight 250kg/gross weight 290kg | Net weight 250kg/gross weight 290kg |
