MF DC resistance automatic double side spot welding stainless steel inverter metal equipment machines price spot welding machine
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
High efficiency spot welding machine spot welder
-
Industry Automatic Pneumatic Ac Multi Resistance Spot Welding Machine
-
DC inverter spot welding machine intermediate frequency spot welder with CE Certificate
-
Pedal Type Resistance Spot Welding Machine , Foot Operated Rocker Arm point Welder, point welding machine
-
Spot welding machine for car dent spoter/spoter welder/China car body repair spot
-
Cnc Spot Welding Machine For Metal Welder
Product Description
Product Description
Feature
The power supply unit's duty are balanced. Three phase power make MD frequency inverter more adaptable in winding and pressure
of wire.
More preaser, faster current control, can analyse parameters more and faster compare with power frequency system.
Faster to set up current, the speed is 20folds quicker than traditional technic
Process more reliable: the majority of the application of solder DC welding metal effect will be even better.
Reduce operating costs, including energy savings each and every point of welding as well as shortening the welding cycle.
Save energy :especially suitable for welding thick workpieces and high-conductivity metal .such as aluminum and galvanized
steel sheet.etc.
of wire.
More preaser, faster current control, can analyse parameters more and faster compare with power frequency system.
Faster to set up current, the speed is 20folds quicker than traditional technic
Process more reliable: the majority of the application of solder DC welding metal effect will be even better.
Reduce operating costs, including energy savings each and every point of welding as well as shortening the welding cycle.
Save energy :especially suitable for welding thick workpieces and high-conductivity metal .such as aluminum and galvanized
steel sheet.etc.
Specification
Item Model | Maximum Short Current KA | Rated Duty Cycle % | Secondary Voilage V | Rated Power KVA | Electrode Pressure N | Electrode Stroke mm | Cooling Water Lmim |
MD-10T | 10 | 50 | ≈9.8 | ≤20 | 1200 | 50 | 20 |
MD-20 | 20 | 50 | ≈9.8 | ≤50 | 4700 | 80 | 24 |
MD-25 | 25 | 50 | ≈9.8 | ≤70 | 4700 | 80 | 24 |
MD-40 | 40 | 50 | ≈11.6 | ≤120 | 7300 | 80 | 30 |
MD-60 | 60 | 50 | ≈11.6 | ≤160 | 12000/18000 | 100 | 50 |
MD-80 | 80 | 50 | ≈11.6 | ≤240 | 12000/18000 | 100 | 50 |
MD-120 | 120 | 50 | ≈11.6 | ≤300 | 18000 | 100 | 60 |
