FRENIC-VP Fuji Frequency Converter Series
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2015
Annual Export Value:
US$1.5 Million - US$2.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Latest Original Fuji Frequency Converter FRENIC-VP Series FRN0018 0013 0009 0025 0031 0037 0044 0059F2S-4CNegotiableMOQ: 1 -
Siemens V20 Frequency ConverterNegotiableMOQ: 1
-
Siemens V20 Frequency Converter 0.37/0.55/0.75/1.1/1.5/2.2/3/4/5.5/7.5/11kw Siemens Frequency ConverterNegotiableMOQ: 1
-
Factory Direct Selling Vector Universal Frequency Converter 3KW / 4kw 220VNegotiableMOQ: 1
-
V8 2S 4R0GB New Hot Selling Products of the Factory Vector Frequency Converter General Frequency ConverterNegotiableMOQ: 1
Product Description
Product features
① Realize the optimal control of air conditioning equipment and improve the energy-saving effect
Air conditioning equipment needs to precisely control the operation of cooling tower fan and cooling water pump according to different flow, pressure and temperature of circulating cooling water. The standard accessory "user customized logic" of this product has powerful calculation function and realizes the * optimal control of air conditioning equipment. Therefore, the power consumption is reduced by about 45% compared with previous products.
Standard with new functions and custom logic |
● constant temperature difference control and estimated end pressure control can be carried out by organizing user-defined logic |
● the user can create separate time series. |
● up to 200 levels can be combined. No special environment is required |
● digital logic circuit or analog calculus circuit can be formed by digital and analog input and output signals |
● logic set by password function can be protected |
② More operable touch screen with remote operation
The communication touch screen (optional) can display "current value", "set value", "power consumption" and other information. Even if it is far away from the frequency converter host, it can confirm and control the operation status of the air conditioning equipment in time.
● the operation panel is equipped with a separate RS-485 port (terminal block) as standard |
● optional with USB operation panel for communication with PC |
● after installing the option card, it can support various communication interfaces. I / O series: relay output, analog input / output, temperature measurement resistance input (PT100)
Communication Series:DeviceNet, PROFIBUS-DP, LonWorks, CC link
|
● removable interface board is adopted |
●Support for multiple languages |
Specification
Applicable motor capacity |
model |
Dimension (W × H × D） |
3.7kW |
FRN0009F2S-4C |
140mm×130mm×143mm |
5.5kW |
FRN0013F2S-4C |
180mm×220mm×158mm |
7.5kW |
FRN0018F2S-4C |
180mm×220mm×158mm |
11kW |
FRN0023F2S-4C |
180mm×220mm×158mm |
15kW |
FRN0031F2S-4C |
220mm×260mm×190mm |
18.5kW |
FRN0037F2S-4C |
220mm×260mm×190mm |
22kW |
FRN0044F2S-4C |
220mm×260mm×190mm |
30kW |
FRN0059F2S-4C |
250mm×400mm×195mm |
37kW |
FRN0072F2S-4C |
250mm×400mm×195mm |
45kW |
FRN0085F2S-4C |
326mm×550mm×261mm |
55kW |
FRN0105F2S-4C |
326mm×550mm×261mm |
75kW |
FRN0139F2S-4C |
361mm×615mm×276mm |
90kW |
FRN0168F2S-4C |
361mm×675mm×276mm |
110kW |
FRN0203F2S-4C |
361mm×740mm×276mm |
132kW |
FRN0240F2S-4C |
536mm×740mm×321mm |
160kW |
FRN0290F2S-4C |
536mm×740mm×321mm |
200kW |
FRN0361F2S-4C |
536mm×1000mm×366mm |
220kW |
FRN0415F2S-4C |
536mm×1000mm×366mm |
280kW |
FRN0520F2S-4C |
686mm×1000mm×366mm |
315kW |
FRN0590F2S-4C |
686mm×1000mm×366mm |
