NK200 Factory Original Cheapness Series Integrated Numerical Control System Cnc Machining 5 Axis Cnc Controller
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2015
Annual Export Value:
US$1.5 Million - US$2.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
The New Richato F1410 DSP Stone Specific Dotting Motion Control System is Used in Stone Processing IndustryNegotiableMOQ: 1 -
RichAuto F731 Three Axis CNC Control System Dsp is Used for 3d Woodworking Cutting MachineNegotiableMOQ: 1
-
RichAuto F741 Servo Stepper DSP Controller Stereo Round Carving Motion Control SystemNegotiableMOQ: 1
-
NK200 Series Integrated Numerical Control System Cnc Machining 5 Axis Cnc Controller Manufacturer's Original Popular CNCNegotiableMOQ: 1
-
NK200 5 Axis Cnc Controller Series Integrated Numerical Control System Cnc Machining 5 AxisNegotiableMOQ: 1
Product Description
NK200 Series Integrated numerical control system
Specification
Model | NK260 / NK280 |
Number of standard control axes | 5 Axis |
CPU | Arm Cortex-A8 |
Dominant frequency | 800GHz |
Memory | 512MB |
Flash | 512MB |
Network port | 1000Mbps |
Display size | 8 inch display |
resolving power | 800×600 |
I/O | 16 channels of cascade output (80 / 16 channels of non-standard configuration) and 16 channels of cascade output (80 / 4 channels in total) |
performance index | ●After electromagnetic interference, group pulse and surge test, the product meets the fourth level protection standard of GB / T 17626.5-2008 ●The seismic resistance meets the standard of GB / T 2423.10-2008 ●After high and low temperature test, it meets the industrial standard (GB / T 2423.102-2008) |
Analog voltage output | 0-10V control |
Magazine type | Support direct row ，Disc magazine |
Tool setting mode | Support automatic ，Manual tool setting |
Tool setting type | Fixed tool setting, floating tool setting, first tool setting / tool setting after tool change |
Compensation mode | Lead screw error compensation, reverse clearance compensation, image error compensation, tool compensation |
Supported file formats | *.g；*.nc；*.ug;*.demo;*.iso;*.eng;*.cut;*.dxf;*.plt;*.txt |
Internet | Establish local area network and front USB interface to realize two-way transmission with PC |
Coordinate system setting | It supports G54-G59 coordinate system and 119 extended coordinate systems |
Processing technology | Array function, rotating mirror image, layered processing, circular processing |
Convenient operation | Handwheel guidance, breakpoint continuation and tool selection processing |
Multiple interpolation algorithms | T-shaped, S-shaped |
Software language | Support Chinese and English |
Control software alarm | Program error, operation error, over range error, PLC error, IO communication error |
Outline dimension drawing
Sheet metal opening drawing
Product detail drawing
Packing & Delivery
FAQ
Q: Do you support customized manufacturing?
A: Yes,we can customized manufacturing according to customer's requirment. We support to OEM your own company display interface and logo.
Q: How long is your delivery time?
A: Generally it is 3-5 days if the goods are in stock. or it is 5-10 days if the goods are not in stock, it is according to
quantity.10-20 days if customized manufacturing.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample with sample price.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=1000USD, 70% T/T in advance ,balance before shippment.
