Deep Drawing Hydraulic Press/Carbon Steel Products Drawing Hydraulic Machine for Electric Water Heater Cover
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2009
Annual Export Value:
Above US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Horizontal Automatic Two-end Inward Bending Machine for PPGI Outer Tank Production of Electric Water HeaterNegotiableMOQ: 1 -
Single-end Inward-bending Machine for PPGI Outer Tank of Electric Water HeaterNegotiableMOQ: 1
-
Electric Water Heater Circular Seam Welding MachineNegotiableMOQ: 1
-
Sheet Roller Machine for Water Heater ProductionNegotiableMOQ: 1
-
Electric Water Heater Decoil LineNegotiableMOQ: 1
Deep drawing hydraulic press/Carbon steel products drawing hydraulic machine for electric water heater cover
Product Description
|
Hydraulic Press machine feature |
1). Working pressure and slide stroke can be adjusted . |
| 2).Column and piston rod with heat treatment to extend their life | |
| 3). Oil cylinder adopt welded steel frame rigid to deflection moment. Shot blasting and specially treated against RUST. |
|
| 4). Overload overflow protection is outfitted to hydraulic system, can assure no leakage,and the oil level can be read or seen directly |
|
| 5). Hydraulic support insurance circuit to prevent go down of slide out of control. | |
| 6). Electrical panel with cooling system designed to meet CE Standards and composed of automation and electrical equipments with SIEMENS brand |
|
| Packaging | Wrapped by plastic films and fixed by steel wires in the Containers |
| Payment | T/T, L/C |
| Delivery Time | Within 30 Days after We get your 30% Deposit |
| Shipping Port | Qingdao Port |
Model(part):
| MODEL | Nominal force |
Stroke of slide |
Daylight | Dimension | Motor | ||
| L-R | F-B | Height | |||||
| KN | mm | mm | mm | mm | mm | KW | |
| R-40 | 400 | 350 | 500 | 1800 | 1200 | 2600 | 4 |
| R-63 | 630 | 400 | 700 | 2400 | 1400 | 3100 | 7.5 |
| R-100 | 1000 | 600 | 900 | 2700 | 1700 | 3400 | 11 |
| R-200 | 2000 | 700 | 1100 | 2825 | 1500 | 3725 | 15 |
| R-315 | 3150 | 800 | 1250 | 3235 | 1500 | 4295 | 18.5 |
| R-400 | 4000 | 800 | 1250 | 3235 | 1500 | 4500 | 22 |
Packaging & Shipping
Customer Visits
Our Services
1. Technical support
2. 30 years experience
3. Oversea service
4. 12month free warranty
FAQ
- Does engineer could help install overseas?
YES. But the cost on customer side
- Do you offer free-warranty
YES. One year
- If the color of machinery be changed.
YES. As you like
- What's the mex. thickness it processed?
0.8mm, could customized 1.2mm too
