AC Voltage Detector 90V to 1000V electrical voltage test Pen
High quality non contact AC voltage detector
AC Voltage Detector 90V to 1000V electrical voltage test Pen
Specifications
|
Specifications |
|
|
Display |
Bar graph |
|
Range of voltage detection |
high sensitivity AC12~1000V. Low sensitivity: AC48~1000V |
|
frequency |
50/60Hz |
|
Alarm mode |
Sound and light alarm |
|
Probe shape |
Prolate shape |
|
Backlight |
Red and green double color backlight |
|
Live and Neutral |
According to backlight color change: green is neutral wire; red is live wire. |
|
Signal intensity display |
Four level sensitivity of bargraph |
|
Signal intensity indication method |
sound from slow to fast; backlight from green to red; bargraph from low to high |
|
Flashlight |
No operation, no sensing signal will shut down automatically in about 3 minutes. |
|
Auto power off |
No operation, no sensing signal will shut down automatically in about 3 minutes. |
|
Low-battery indication |
√ |
|
Power Supply |
2x1.5V AAA batteries |
|
Weight |
Approx.32g |
|
Size |
157mm x 27mm X 23mm |
|
Safety rating |
EN61010-1,-2-030; EN61326-1, CAT lll 1000V |
AC Voltage Detector 90V to 1000V electrical voltage test Pen
AC Voltage Detector 90V to 1000V electrical voltage test Pendetector
AC Voltage Detector 90V to 1000V electrical voltage test Pen
-Do we support OEM or ODM?
-Will the original R&D manufacturing paint have a price advantage?
-Are you products high quality products?
-Do we have a good team?
-Does our product support global after-sales service ?
-Are our product certified?
every answer is "YES"
