HT-113B
Digital Multimeter With T-RMS/Autorange
product feature
-resistance measure up to 60mΩ with continuity detection
-large dual backlight diaplay with 4000 counts
-voltege measurement
-manual power off
-low battery indication
-backlight
-the data hold
-true RMS measrument
product image
Specifications
Specifications | Range | Accuracy |
|
| HT113B |
DC Voltage | 400mV/4V/40V/400V/600V | ±(0.5%+3) |
| 600mV/6V/60V/600V |
|
AC Voltage | 400mV/4V/40V/400V/600V | ±(1.0%+3) |
| 600mV/6V/60V/600V |
|
| 400uA/4000uA/40mA/400mA | ±(1.2%+3) |
DC Current | 600uA/600uA/60mA/600mA |
|
| 10A | ±(2.0%+3) |
AC Current | 400uA/400uA/40mA/400mA | ±(1.5%+3) |
| 600uA/6000uA/60mA/600mA |
|
| 10A | ±(2.0%+3) |
Resistance | 400Ω/4KΩ/40kΩ/400kΩ/4MΩ/40MΩ | ±(1.0%+3) |
| 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ |
|
Capacitance | 10nF/100nF/1uF/10uF/100uF/1mF/10mF |
|
| 100mF |
|
Frequency | 10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz |
|
Duty | 1%~99% |
|
Display | 4000 Counts | |
Auto/Manual range | Auto | |
General
Power supply:2x1.5V AAA batteries
Product size:151mm*75mm*48mm
Product weight:Approx.220g
Safety rating:EN61010-2-030
EN61010-2-033
CATIII 600V
