XNR-400B Plastic Melt Flow Index Tester/mfi Tester
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2009
Factory Size:
1,000-3,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HST-6019 Rotational Rheometers for Measuring Viscosity and Viscoelasticity.NegotiableMOQ: 1 -
Model XNR-400B Automatic Melt Flow Index Tester With MFR MethodNegotiableMOQ: 1
-
XNR-400D LCD Display LDPE PE Plastic Melt Flow Index TesterNegotiableMOQ: 1
-
HST-6024 Rubber Vacuum Type Oil Seal Trimming Rubber Testing MachineNegotiableMOQ: 1
-
HS-FT Schopper Riegler Beating Freeness TesterNegotiableMOQ: 1
XNR-400T Touch Screen Display Plastic Melt Flow Index Tester mfi tester
2. Product features:
High-precision Chinese and English color controllers, specially customized membrane buttons, have
unparalleled advantages in control accuracy and service life
The manual and automatic cutting are integrated control, accurate to 0.1s, and the cutting time and cutting
times can be set arbitrarily.HST Group Co.,LTD.
Built-in micro printer, which can print test data
Dual temperature control system, using double imported heating coils and double imported PT100
platinum resistance sensors to improve test accuracy and temperature stability.
Increase the displacement sensor, can test MVR (volume method), the accuracy is 0.01mm.
The volume method test does not need to be cut, and the test result can be directly output
The density value of the material at a specific temperature can be calculated by the ratio of the volume
method and mass method
It can be connected to the computer via USB, and the test conditions can be set on the computer through
the software, and the data can be printed and stored (optional).
3. Test method: mass method, volume method (MFR, MVE)
4. Display mode: 4.3 color touch screen display
5. Main technical parameters:
Temperature range: 0℃-450℃
Temperature fluctuation: ±0.2℃
Temperature uniformity: ±1℃
Temperature display resolution: 0.1℃
Time display resolution: 0.1S
Die diameter: Φ2.095±0.005mm
The length of the discharge port: 8.000±0.025mm
The diameter of the charging cylinder: Φ9.550±0.025mm
Weight accuracy: ±0.5%
Displacement measurement accuracy: 0.01mm
Volume method timing accuracy: 0.001S
Displacement measurement encoder: Omron photoelectric rotary encoder
Quality method test range: 0.1-150g/10min
Volume method test range: 50-5000cm³/10min
Output mode: micro automatic printout
Cutting method: manual and automatic cutting in one
Test load: a full set of eight-level weights
Power supply voltage: AC220V±10% 50HZ
Technical parameters:
XNR-400B Plastic Melt Flow Index Tester
