Fiber Cable And Wire Tensile Testing Machine Cable Torsion Tester/Cable Testing Equipment
Application
Optical Fiber Cable Repeated Bending Tester is used to determine the ability of a fiber optic cable to
withstand repeated bending (cyclic flexing).
Optical Fiber Cable Impact Tester Series allows a cable sample to be bent backwards and forwards at an
angle of 180° by bending extreme ends of cables at 90° in opposite directions, while the sample is
subjected to a tensile load.
The bending arm is designed to hold the cable securely during the entire test, without crushing the optical
fibers or inducing optical loss. The bending radius is controlled by replaceable cushioning reels, chosen
T o match the cable bending radius. The machine is capable of cycling at a rate of 30 cycles per minute.
Specifications
Technical Parameters | |
Model |
HST-GLQ-1000 |
Bending angle |
±90° |
Maximum bending cycles |
1-9999 cycles |
Frequency range |
10 – 30 cycles / min |
Bending radius |
75,100,125, 150, 175, 200, 225, 250, 275, 300, 375 mm (others upon request) |
Mass of weights for applying tension |
1-10 kg (other upon request) |
