TPJ 10kn springs dynamic and static small compression spring fatigue testing machine price
Application:
This machine is mainly used for various spiral spring, disc springs and shock absorbers,seal springs, and the fatigue life of test. Widely used in spring, shock absorber production, application etc.
Main features:
1. according to the technical requirements of the spring, to adjust the amplitude and frequency of the spring.
2. LCD display, frequency and the number of tests according to your requirment to enter the
program, auto-complete.
3. preset the number of tests and automatically shut down.
4. consists of motor, reducer to connecting with cams to drive connecting rod for reciprocating motion to achieve the compression of the spring.
5. the operator can achieve high load, high frequency, low consumption, thereby reducing the
test time and reduce the testing costs.
coil spring fatigue testing machine specification:
|
Model |
TPJ-5 /TPJ-10 /TPJ-20 |
|
Max testing force |
5kN,10kN,20kN |
|
Max sample length |
400mm(can be customized) |
|
Max sample diameter |
Φ300mm(can be customized) |
|
Testing frequency |
0~5Hz |
|
Amplitude |
Max:100mm |
|
counter capacity |
999999999 |
|
Working voltage |
220VAC/50Hz |
|
|
|
| 10N-10KN Touch scree spring tension compression tester | 10N-5KN Digital display spring tension compression tester | 10N-5KN Digital display spring tension compression tester |
|
|
|
| 20N-5KN Digital display spring tension compression testing machine | 10-100kn spring tension compression testing machine | Spring fatigue tester |
|
|
|
| Spring torsion tester | Spring fatigue tester | Spring torsion testing machine |
Dear customer, if you need our testing machines, please send us inquiry without any hesitate ! We will supply our best service for you ! Please send us "inquiry" !
-------------
