TLW Series 10-300KN Computer Control Automatic Tensile and Compression Spring Testing Machine
- T/T Credit Card
You May Like
-
HST Automatic Cable Metal Wire Spring Material Universal Torsion Tester 200N.m TNZ-200
-
HST TNZ-10 Metal Wire Torsion Testing Machine, Torsion Spring Testing Machine
-
HST Stainless Steel Spring Test Reverse Tester Wire Torsion Tester And CE Certificate
-
HST High Precision Automatic Spring Torque Tester Digital Flat Coil Spring Torsion Testing Machine
-
HST 1000N.mm Digital Spring Torsion Testing Machine
-
HST Manual Spring Tensile or Extension and Compression Testing Machine or Torsion Tester
Product Description
TLW Series 10-300KN Computer Control Automatic Spring Tensile and Compression Testing Machine
Application
This series testing machine is mainly used for tension spring, compression spring, saucer reed, tower spring, leaf spring, clip spring, flat spring, cpmposite spring,gas spring, mould spring, deformed spring and other precision spring tensile, compression, disp lacement and rigidity test and analysis.
Standards
GB/T, ASTM, DIN, JIS and other international standards
Main Technical Parameters
|
Model |
TLS-10 TLW-10 |
TLS20 TLW-20 |
TLS50 TLW-50 |
TLS-100 TLW-100 |
TLS-200 TLW-200 |
TLS-300 TLW-300 |
||||
|
Structure |
Single Colum Type Double space models |
|||||||||
|
Control Method |
Digital display/computer control |
|||||||||
|
Load Accuracy |
Class1/Class0.5 |
|||||||||
|
Load Range |
2%~100%F·S |
|||||||||
|
Test force relative error value |
≤±1%% |
|||||||||
|
Displacement relative error value |
≤±1% |
|||||||||
|
Displacement display resolution |
0.01mm |
|||||||||
|
Deformation indication error |
≤±(50+0.15L)um |
|||||||||
|
Speed range(mm/min) |
0.01-500 |
0.01-500 |
0.01-500 |
0.01-500 |
0.01-500 |
0.01-500 |
||||
|
Speed relative error |
≤±1% |
|||||||||
|
Tensile test space |
670 |
670 |
770 |
650 |
700 |
700 |
||||
|
Compression space |
670 |
670 |
770 |
650 |
700 |
700 |
||||
