Q-100B Metallurgical Cutting Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2009
Factory Size:
1,000-3,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SQ-60 Metallographic Specimen Cutting Machine/sample Cutter for PetrographicUS$ 8747.38 - 9027.30MOQ: 1 Set -
GTQ-5000B Metallographic Sample Thin Section Equipment/ Specimen Precision Cutting MachineUS$ 18887.34MOQ: 50 Sets
-
SQ-80 Manual Metallographic Sample Cutting Machine in Testing EquipmentUS$ 8397.48 - 9797.06MOQ: 1 Set
-
Metallographic Specimen/ Sample Cutting MachineNegotiableMOQ: 1
-
DTQ-5 Low Speed Diamond Blade Specimen Cutting MachineUS$ 1000 - 1500MOQ: 1 Set
Metallurgical cutting machine
Q-100B Metallographic Cutting Machine
Metallographic Cutting Machine Application:
Model Q-100B manual / automatic metallographic specimen cutting machine is equipped with big cutting room and movable T-shape work table. Therefore this machine has the ability of cutting rectangle and large specimens. Also the equipped separate type vice is very convenient for operator to clamp various heterotypic work pieces.
Metallographic Cutting Machine Technical specifications
- Various cutting data can be displayed on high definition backlight type LCD screen.
- Cutting diameter: Ø5-100mm
- Cutting volume: Ø100mm x 200mm
- Manual cutting and automatic cutting means can be switched at will
- Large cutting chamber, tempered glass observing window
- Equipped with 60L cooling liquid water tank.
- Non-burning loss swing type cutting means that improved the cutting quality
- Automatic withdraw function after cutting is finished
- Bidirectional feeding means increase the length of deep cutting
- Cutting speed: 2.25, 3, 4, 5, 7, 9, 12, 15mm/min.
- Sand wheel rotating speed: 2100rpm
- Sand wheel specification: 350 x 2.5 x 32mm
- Display: LCD with high resolution backlit dot matrix
- Power: three phases with four cables, 380V, 50Hz.
- Dimensions: 930 x 700 x 610mm
- Net weight: 220 KG
