1000t hydraulic steel wire rope swaging press machine
1. Application:
Hydraulic Steel Wire Rope Swaging Machine is a new generation of wire rope rigging processing equipment, which is developed with advanced technology and processes . This machine with compact institution, easy to operate, high efficiency, beautiful appearance. Certificated by EU standards-CE.Pressed slings are with high strength conclude and safe load. Comparing with conventional splicing technology, pressing machine can greatly improve the processing efficiency and save wire rope. Pressing machine have widely used in metallurgy, mining, ports, railways, electricity and other industries. We have exported to UK, Australia, the Netherlands, Malaysia, Poland, South Africa, Thailand, Russia, Latvia and so on.
2.Features:
1. Overall basket design, small size, high strength, good concentricity, pressed slings with smooth surface
2. The body of swaging construction is manufactured from one single block construction that ensure stress uniform, high strength, long service life.
3. We use latest materials, Combined seals and ultra-wearable guide ring between the the piston rod and the cylinder, so that the cylinder is with higher sealing performance, safe, reliable and durable
4. Round mold design and automatic positioning is easy to change different molds.
3. Technical parameter:
|
Model No. |
HST-2000T |
|
Max wire rope diameter (mm) |
Φ6-Φ76 |
|
Power (KW) |
15 |
|
Max working pressure (Mpa) |
56Mpa |
|
Max piston movement (mm) |
200 |
|
The up speed of piston (mm/sec) |
10 |
|
The down speed of piston (mm/sec) |
10 |
|
Total length (mm) |
2500 |
|
Total width (mm) |
1300 |
|
Total height (mm) |
2200 |
|
Net weight (kg) |
6500 |
