YAW-2000D Calculates Automatically Computer Control Electric Screw Concrete Compression Testing Machine
Contact: Claire Whatsapp/Wechat:86-15866781190 skype:hstbetty009
1. Main Application
YAW-D Series Compression Testing Machine mainly used for concrete rupture strength testing, cement, plastic sand, and red brick building materials compression resist testing. Widely used in metallurgy, building materials, space flight and aviation, colleges and universities, R&D institution lines. The test operation and data processing meets standard requirements.
2. Product description:
2.1 Computer control up, down, test, stop and loading progress
2.2 Electric screw ball adjust test space
2.3 Unibody desktop oil source control cabinet
2.4 This machine consist of the host machine, oil source and control system.
2.5 Can realize the load rate, such as load or stress rate loading
2.6 Can auto printing
3. Main Technical Parameters
|
Model |
YAW-2000D |
|
Max. Load |
2000kN |
|
Control method |
Computer auto control loading process |
|
Oil source control cabinet structure |
One-piece oil source control cabinet |
|
Test class |
1 class |
|
Testing range |
4%-100%FS |
|
Load display accuracy |
Better than ±1% |
|
Piston diameter X maximum stroke |
250x50mm |
|
Distance between upper and lower platen |
320mm |
