HST YES-2000 200 Ton Concrete Cube Block Compression Testing Machine

FOB Price

Negotiable

1 (Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

YES-2000 200ton Concrete Cube Block Compression Testing Machine

1.Application:

YES-2000 Digital Display Compression Testing Machine mainly used for Concrete Cube and other

material compression resist testing.

Widely used in metallurgy, building materials, space flight and aviation, colleges and universities,

R&D institution lines. The test operation and data processing meets standard requirements.

2.Standards:

GB/T, ISO, ASTM, DIN, JIS, etc.

3.Main Specifications:

Model	YES-2000
Max. Load	2000 kN
Class	1 Class
Testing Space Regulating Way	Manual Ball Screw Adjust
Control Way	Manual Control Load Way
Oil Source Control Cabinet Structure Form	One-piece Bench Oil Source Control Cabinet
Range Of Test Force	4% ~100% FS
Indicating Value Accuracy	±1%
Piston Stroke	50mm
The Largest Spacing Of Upper And Lower Pressure Plate	320mm
The Largest Spacing Of Two Columns	270mm
Pressure Plates Size	250250mm(LW)
Display	LCD Digital Display
The Host Dimension	900×400×1150mm
Power Supply	1KW/AC380V
Weight	750 KG
