300kn Computer Control Electro-hydraulic Servo Universal Tensile Strength Measuring Instrument

Model

WAW-100B

WAW-300B

WAW-600B

WAW-1000B

structure

Two column Two ball screw

Control mode

constant stress, deformation, displacement,

three closed loop control

Max. Load

100kN

300kN

600kN

1000kN

Load range

2%~100%FS

Force resolution

1/300000

Load accuracy

≤±1%

Test force resolution value

0.01kN

Deformation Measurement Range

2% ~ 100% of extensometer

measurement range

Deformation indicating relative error

± 0.5%of indicating value

Deformation resolution

0.001mm

Displacement Indication Error

1%of indicating value

Displacement Resolution

0.01mm

Clamping Method

Hydraulic clamping

Control range of stress rate

1MP/S-60MP/S

Adjust range of test strain rate

0.00025/S-0.0025/S

Control range of displacement rate:

0.5mm/min-50mm/min

Gantry adjust speed

150mm/min

Max piston stoke

250mm

Max. Tensile Test Space

650mm

Max.Compression Test Space

500

Round Sample Clamping Diameter

Φ6-Φ13mm

Φ6-Φ26mm

Φ13-Φ26mm

Φ13-Φ40mm

Flat Sample Clamping Diameter

0-15mm

0-15mm

0-15mm

0-30mm

Clamping width of flat sample

70mm

70mm

75mm

75mm

Pressure Plate Size

Φ160/204x204(optional)

Bending Test Branch Roller Width

140mm

Roller distance of bending

600mm

Voltage

380V/50Hz/3Phase(can be customized)

Overall Dimension(LxWxH)

660×500×1800

740×580×2050

820×660×2250
