WAW-L Steel Computer Control Material Single Tensile Testing Machine
1. Application:
This High Frequency Material Tensile Testing Machine is applied in the steel industry, quality inspection stations and other high-frequency, high-fatigue fast metal tensile test.
Contact: Alice Skype: hssdtest What's APP / TEL: +86-15098778967 Ali: cn1001290168
2.Structure
The machine consists of three parts: main unit, oil source, measurement and control system. Computer automatic control rising, falling, test, stop, etc..
3.Features:
3.1 Semi-open jaws seat, rigid, no deformation;
3.2 Double-clip grip,holding firm, non-skid;
3.3 Long cylinder stroke make construction more reasonable, durable;
3.5 Double pump structure independent oil source to improve the test speed.
4.Technical parameter:
Model | WAW-300L | WAW-600L | WAW-1000L | WAW-2000L |
Max Load | 300kN | 600kN | 1000kN | 2000kN |
structure | Four columns single pull frame structure | |||
Control way | Constant stress, constant deformation, constant displacement three closed-loop control and programming control | |||
Test class | 1 class | |||
Test force range | 2%-100%FS | |||
Test value relative error | Better than ±0.5% | |||
Test force resolution | 20000 yard | |||
Deformation effective test range | 2%~100%FS | |||
Deformation resolution | 20000 yard | |||
Deformation value relative error | Better than ±0.5% | |||
Displacement resolution | 0.01mm | |||
Displacement value relative error | Better than ±1% | |||
Piston unload maximum speed | 0.1-100mm/min stepless | |||
Cylinder piston stroke | 500mm | 650mm | ||
Max tensile space | 600mm | 700mm | ||
Specimen clamp way | Hydraulic double-clip | |||
Tensile grip Round specimen clamp diameter | Φ6-Φ40mm | Φ13-Φ60mm | Φ13-Φ60mm | Φ26-Φ70mm |
Tensile grip flat specimen clamp diameter | 0-30mm | 0-40mm | 0-50mm | 0-60mm |
