Home > Products > Hydraulic Universal Testing Machine > HST material tester Hydraulic Universal Tensile Test Machine 1000kn hydraulic universal testing machine
HST material tester Hydraulic Universal Tensile Test Machine 1000kn hydraulic universal testing machine
- 1000 per Month
- T/T Credit Card
You May Like
-
HST materials machines metal testing machine hydraulic servo
-
HST hydraulic universal tester material Hydraulic Universal Tensile Test mechanical testing equipment
-
HST shimadzu testing machine Electro-hydraulic Servo Universal Testing Machine servo hydraulic
-
HST material Hydraulic Universal Tensile Test equipment servo hydraulic composite materials testing
-
HST Laboratory Servo Hydraulic Universal Testing Machine Price china 100kn test machine
-
HST 100KN Computerized Ultimate Universal Testing Machine hydraulic compression hydrostatic testing machine
Product Description
HST material tester Hydraulic Universal Tensile Test Machine 1000kn hydraulic universal testing machine
Contact: Alice Skype: hssdtest whatsapp /hst/mobile:17853101076
1. Application
Universal Tensile Strength Testing Machine price is suitable for tension, compression,
bending, shearing,peeling, tearing and other tests by adding different test fixture for metal and nonmetal materials. It is widely used in inspection department, engineering area, laboratories, universities and institutes for material properties research and quality control.
2. Standards of universal testing machine price
ISO75001, ASTM A370, ASTM E4, ASTM E8 and BSEN standards
3. Main specifications universal testing machine price
Model | WAW-100D | WAW-200D WAW-300D | WAW-600D | WAW-1000D/E | WAW-1200E | ||||
Control Way | Constant stress uniform deformation constant displacement three closed loop control and program control dealing | ||||||||
Number of Screw drivers | 4 | ||||||||
Max. Load(KN) | 100 | 200 /300 | 600 | 1000 | 1200 | ||||
Load Accuracy | ≤± 1%/ ≤± 0.5% | ||||||||
Load Range | 2%~100%FS | ||||||||
Load Resolution | 1/300000 | ||||||||
Deformation Measurement Range | 2%~100%FS | ||||||||
Deformation Accuracy | ≤± 1% | ||||||||
Displacement Resolution | 0.01mm | ||||||||
Testing speeds (mm/min) | 0.1~118 | 0.1~123 | 0.1~123 | 0.1~70 | 0.1~70 | ||||
Adjustable crosshead speed(mm/min) | 450 | 450 | 350 | 350 | 320 | ||||
Displacement Error | ≤±0.5% | ||||||||
Max. Piston Stroke(mm) | 200 | 200 | 200 | 200/250 | 250 | ||||
Max. Tension Test Space (mm) | 780 | 780 | 900 | 950/980 | 930 | ||||
Max. Compression Test Space | 550 | 550 | 650 | 700 | 640 | ||||
Column Effective Spacing(mm) | 485 | 485 | 500 | 560/580 | 610 | ||||
Clamping Method | Hydraulic Automatic Clamp | ||||||||
Flat Specimen Clamping Width(mm) | 80*80 | 80*80 | 90*90 | 100*100 | 120*110 | ||||
Compression Plate Size | Φ 160mm | ||||||||
Bending Roller Distance | 450mm | ||||||||
Width Of Bending Rollers | 120mm | ||||||||
Power Supply | 3-phase, AC380V, 50Hz (Can Be Customized) | ||||||||
