Chinese supplier laboratories equipment 300KN 30 Ton metals electronic universal tensile testing machine



Chinese supplier laboratories equipment 300KN 30 Ton metals electronic universal tensile testing machineChinese supplier laboratories equipment 300KN 30 Ton metals electronic universal tensile testing machineChinese supplier laboratories equipment 300KN 30 Ton metals electronic universal tensile testing machine

1.Application:

It is applicable for wide range of material for tension, compression, bending, shearing and low cycle test. Suitable for metal, rubber, plastic, spring, textile, and components testing. It is widely used in the corresponding industries, research and development, test institutes and training centers etc.

2.Standards:

ASTMA370,ASTME4,ASTME8,ASTME9,ISO6892,ISO7438,ISO7500-1,EN10002-4,GB/T228-2002,etc.

3.Specifications:

Model

WDW-200

WDW-200E

WDW-300

WDW-300E

Max. Load(kN)

200

200

300

300

Structure

Four-column floor or desk model,

(upper is compression and lower is tensile)

Cover

All aluminum alloy

Control method

Computer control

Load accuracy

Class 1

Class 0.5

Class 1

Class 0.5

Load range

2%~100%F·S

0.2%~100%F·S

2%~100%F·S

0.2%~100%F·S

Load resolution

1/300000

Rang of deformation

4%-100%FS

Resolution of deformation

0.04um

Accuracy of displacement

Within±0.5%of indicating load

Resolution of displacement

0.01mm

Test speed(mm/min)

0.05-200 stepless arbitrary setting

Tensile space(mm)

550(can be customized)

Compression space(mm)

550(can be customized)

Test width(mm)

600(can be customized)
