100 KN 200 KN 300 KN Tensile Strength Tester PC Servo Universal Testing Machine

100 KN 200 KN 300 KN Tensile Strength Tester PC Servo Universal Testing Machine thumbnail-1
100 KN 200 KN 300 KN Tensile Strength Tester PC Servo Universal Testing Machine thumbnail-2
100 KN 200 KN 300 KN Tensile Strength Tester PC Servo Universal Testing Machine thumbnail-3
100 KN 200 KN 300 KN Tensile Strength Tester PC Servo Universal Testing Machine thumbnail-4
100 KN 200 KN 300 KN Tensile Strength Tester PC Servo Universal Testing Machine thumbnail-5
100 KN 200 KN 300 KN Tensile Strength Tester PC Servo Universal Testing Machine thumbnail-6
100 KN 200 KN 300 KN Tensile Strength Tester PC Servo Universal Testing Machine photo-1
100 KN 200 KN 300 KN Tensile Strength Tester PC Servo Universal Testing Machine photo-2
100 KN 200 KN 300 KN Tensile Strength Tester PC Servo Universal Testing Machine photo-3
100 KN 200 KN 300 KN Tensile Strength Tester PC Servo Universal Testing Machine photo-4
100 KN 200 KN 300 KN Tensile Strength Tester PC Servo Universal Testing Machine photo-5
100 KN 200 KN 300 KN Tensile Strength Tester PC Servo Universal Testing Machine photo-6
US$ 40587.82 1 - 4 Set
US$ 39188.24 ≥5 Set
Key Specifications
Get Latest Price
brand name:
HST
place of origin:
Shandong, China
customized support:
OEM, ODM, OBM
Contact Supplier Request Quote Chat Now
Hst Group Co.,ltd.
Gold Verified Supplier
1Yr
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
brand name HST
place of origin Shandong, China
customized support OEM, ODM, OBM
power Electronic
warranty 1 year
model number WDW-10 20 30 50/100E
Max test force Geotextile tensile Test Machine
Load accuracy ≤±1%
Load resolution 1/300000 of full scale
Disp. resolution 0.04μm
Test speed 0.005-500mm/min stepless arbitrary setting
Color white and blue (customized)
clamp type Manual clamp (pneumatic/hydraulic clamp for choice)
Test width 550mm
Tensile space n space: 700mm (can be customized)
Motor TaiWan TECO AC Servo Motor

 HST 100 KN 200 KN 300 KN Tensile Strength Tester PC Servo Universal Testing Machine



100 KN 200 KN 300 KN Tensile Strength Tester PC Servo Universal Testing Machine100 KN 200 KN 300 KN Tensile Strength Tester PC Servo Universal Testing Machine

100 KN 200 KN 300 KN Tensile Strength Tester PC Servo Universal Testing Machine









Product Description





1 Application:

WDW series computerized electronic universal testing machines are designed and manufacture according to ASTM, ISO, DIN, GB and other international standards. Applicable for wide range of material for tension, compression, bending, shearing and low cycle test. Suitable for metal, rubber, plastic, spring, textile, and components testing. It is widely used in the corresponding industries, research and development, test institutes and training centers etc.



 2 speicification



Model

WDW-50

WDW-50E

WDW-100

WDW-100E

Max. Load(KN)

50

50

100

100

Load accuracy

Class 1

Class 0.5

Class 1

Class 0.5

Load range

2%~100%F·S

0.2%~100%F·S

2%~100%F·S

0.2%~100%F·S

Structure

Four-column floor or desk model,

(upper is compression and lower is tensile)

Cover

All aluminum alloy

Control method

Computer control

Load resolution

1/300000

Rang of deformation

4%-100%FS

Resolution of deformation

0.04um

Accuracy of displacement

Within±0.5%of indicating load

Resolution of displacement

0.01mm

Test speed(mm/min)

0.05-500 stepless arbitrary setting

Tensile space(mm)

700(can be customized)

Compression space(mm)

700(can be customized)

Test width(mm)

500(can be customized)

550(can be customized)

Workbench thickness(mm)

58

68

Base height(mm)

435

460

Working environment

Room temperature 10℃~30℃,relative humidity≤80%

Power supply

AC220V±10%,50Hz/60Hz(can be customized)

Grips

Wedge type, plate type and other grips as consumer's demand



Dimension(mm)

850*480*1865

1000*550*2076
