Product Description
Introduction：
KY carton compression tester is the essential testing equipment to test the compressive strength of carton box. Adopted high precise sensor,ARM chip, with powerful data processing function, test process automatic tracking, the testing result is automatic recording, real-time display test data and curve, and can communicate with computer. Touch-screen display make the instrument easy to operate, good appearance , and quick response.
Standards：
ISO2872,ISO2874,GB/T4857.3,GB/T4857.4
Specification
Item | KY10 | KY50 | |
Power supply | AC380V±10% 60HZ | ||
Measuring range | (0.1-10)kN | (1-50)kN | |
Indication error | <±1% | ||
Platen size | 500*500mm (customized) | 800*800mm/1000*1000mm/1200*1200mm/1500*1500mm (customized) | |
Operating stroke | 500mm (customized) | 800mm/1000mm/1200mm/1500mm (customized) | |
Compression speed | 10mm/min | ||
Speed adjustment range | 0.05-300mm/min | ||
Track and force speed in stacking test | 2mm/min | ||
Company Profile
Packing & Delivery
Standard exporting case
