Salt Fog Spray Chamber for Corrosion Resistance Test
1. Function
Salt spray test chamber is used for the quality inspection and corrosion resistance test of a variety of materials, including metal plating, metal, electronic components, chemical coatings, paint, automobiles, motorcycles, metal ware, screws, springs, magnetic materials, organic and inorganic coating, anodizing, anti-rust oil industry etc. after the surface treatment.
2. Corresponding standard :
1.GB/T 2423.17-1993 salt spray test
2.GB/T 2423.18-2000 salt spray test
3.GB/T 10125-1997 salt spray test
4.ASTM.B117-97 salt spray test
5.JIS H8502 salt spray test
6.IEC68-2- 11 salt spray test
7.IEC68-2-52 1996 salt spray test
8.GB.10587-89 salt spray test
9.CNS.4158 salt spray test
10.CNS.4159 CASS Accelerated acetic acid copper salt spray test
11..GB/T 12967.3-91 CASS Accelerated acetic acid copper salt spray test
3.Main Parameters
MODEL |
KS-60 |
KS-90 |
KS-120 |
Temperature inside chamber |
Salt test (NSS ACSS)35℃±1℃/ Corrosion Test (CASS)50℃±1℃ |
||
Temperature of pressure barrel |
Salttest(NSSACSS)47℃±1℃/CorrosionTest (CASS)63℃±1℃ |
||
Inner size (W*D*H) mm |
600x450x400 |
900x600x500 |
1200x800x500 |
External size (W*D*H) mm |
1070x600x1180 |
1410x880x1280 |
1900x1100x1400 |
Temperature Uniformity |
≤±2℃ |
||
Uniformity Fluctuation |
≤±0.5℃ |
||
Salt fog settlement |
1~2ml/h.80cm2 |
||
Compressed air pressure |
1.00±0.01kgf/cm² |
||
Spray mode |
Continuous or intermittent spray optional |
||
Power supply |
AC 220V /50Hz |
||
