HBS-3000 Digital Display Brinell Hardness Tester Price, Steel Hardness Tester
1. Application:
HBS-3000 digital brinell hardness tester is a recently developed new generation Brinell tester that is domestically advanced.It can be applied to determine the Brinell hardness for ferrous metal and non-ferrous metal.The tester adopts electronic auto loading,computer software programming,high power optical measurement,photosensor and other systems.Eash operational process and test manufacturing enterprises,colleges and scientific institutions.
2. Main technical specifications
Model |
HBS-3000 |
|
Type |
Digital Brinell |
|
Test›range |
8~650 HBW (hardmetals steel ball) |
|
Brinell›hardness›test›(N) |
612.5, 980, 1225, 1837.5, 2450, 4900, 7350, 9800, 14700, 29400 |
|
Load›control |
Automatic |
|
Magnification›of›microscope›x |
20x for reading microscope |
|
Max.›height›of›specimens›(mm) |
220 |
|
Max.›depth›of›specimens›(mm) |
135 |
|
Power |
AC220V, 50/60Hz |
|
Dimension›(DxWxH)›(mm) |
550 x 236 x 753 |
|
Net›weight›(kg) |
130 |
|
Packing List |
||
Indenter |
Steel ball indenter í2.5mmx1 í5mmx1 í10mmx1 |
|
Testing›table |
Big / small /V, 1 for each |
|
Hardness››block |
HBW 3000/10 150~250 x 1, HBW 1000/10 75~125 x 1, HBW 187.5/2.5 150~250 x 1 |
|
Operation›manual |
1 |
|
Reading›microscope |
20x x 1 |
|
Micrometer›eyepiece |
1 |
|
