HBRVS-187.5D Digital Display Motorized Brinell Rockwell Vicker
Universal Hardness Tester
1.Application:
HBRVS-187.5D Digital Display Motorized Brinell Rockwell Vickers Hardness Tester is used to
determine the Brinell, Rockwell and Vickers hardness of ferrousmetals, non-ferrous metals and
hard alloys.
It is widely used in the precision measurement of parallel flat surfaces as well as curved surfaces.
2.Main Technical Specifications:
|
Model |
HBRVS-187.5D |
|
Rockwell Scale Test Force |
HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRH, HRK 60Kg (588N), 100Kg (980.7N), 150Kg(1471N) |
|
Brinell Scale Test Force |
HBW2.5/31.25, HBW2.5/62.5, HBW5/62.5, HBW2.5/187.5 31.25Kg(306.5N), 62.5Kg (612.9N), 187.5Kg (1839N) |
|
Vickers Scale Test Force |
HV30, HV100 30Kg(294.2N), 100Kg (980.7N) |
|
Hardness Value Read |
Big Digital LCD |
|
Amplification Times |
37.5X, 75X |
|
Specimen Maximum Height Allowed |
Rockwell: 170mm; Brinell, Vickers: 140mm |
|
Dwell Time |
1~60S |
|
Power Supply |
AC 220V±5%, 50Hz |
|
Instrument Size |
465*180*655mm (L*W*H) |
|
Instrument Weight |
85 KG |
|
Hardness Value Range |
Rockwell, HRA:70~85 HRB:30~100 HRC:20~67 Brinell, HB4-450 Vickers, HV14-1000 |
|
Executive Standard |
GB/T230.2(Rockwell), GB/T231.2(Brinell), GB/T4340.2 (Vickers), JJG112 (Rockwell), JJG150(Brinell). |
