Home > Products > Hydraulic Universal Testing Machine > 1000KN Computer Control Servo Steel Strand Hydraulic Steel Pipe Tensile Testing Machine
1000KN Computer Control Servo Steel Strand Hydraulic Steel Pipe Tensile Testing Machine
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
300kN 600kN 1000KN Hydraulic Universal Tester Tensile Testing Machine Price
-
Electro-hydraulic Single Space Hydraulic Servo Tensile Force Strength Universal Testing Machine
-
WAW-500D 50ton Computerized Electro-servo Hydraulic Universal Testing Machine Price High Quality Hydraulic Equipment 4 Column
-
WAW-2000A 1000KN 2000KN 200Ton Computer Control Servo Hydraulic Universal Tensile Testing Machine UTM Price
-
WAW-600D 600kN/60Ton New Design Hydraulic Universal Rebar Tension Testing Equipment Astm D412 Tensile Strength Test Equipments
-
WAW-1000D 100 Ton Hydraulic Universal Tensile Testing UTM Machine Price
Product Description
1000KN Computer Control Servo Steel Strand Hydraulic Steel Pipe Tensile Testing Machine
Product Description
Application
For static and cuasi-static test (low frequency fatigue) for high loads in many types of tests. Specially indicated to switch test mode, thanks to its dual space design.
EN 10002-2; ASTM E4, ISO 7500-1; DIN 51221 and BS1610 guide, etc.
For static and cuasi-static test (low frequency fatigue) for high loads in many types of tests. Specially indicated to switch test mode, thanks to its dual space design.
Standards
EN 10002-2; ASTM E4, ISO 7500-1; DIN 51221 and BS1610 guide, etc.
Specification
Model | WAW-100D | WAW- 200/300 D | WAW-600D | WAW-1000D/E | WAW-1200D | WAW-2000D | |||||
Control Way | Constant stress uniform deformation constant displacement three closed loop control and program control dealing | ||||||||||
Number of Screw drivers | 4 | ||||||||||
Max. Load(KN) | 100 | 200 /300 | 600 | 1000 | 1200 | 2000 | |||||
Load Accuracy | ≤± 1%/ ≤± 0.5% | ||||||||||
Load Range | 2%~100%FS | ||||||||||
Load Resolution | 1/300000 | ||||||||||
Deformation Accuracy | ≤± 1% | ||||||||||
Testing speeds | 0.1~118 mm/min | 0.1~123 mm/min | 0.1~70 mm/min | ||||||||
Clamping Method | Hydraulic Automatic Clamp | ||||||||||
Power Supply | 3-phase, AC380V, 50Hz (Can Be Customized) | ||||||||||
