Product Description

1000N Spring Tension Strength tensile test Compression Load Testing Machine

Product Description

Introduction

This series testing machine is mainly used for tension spring, compression spring, saucer reed, tower spring, leaf spring, clip spring, flat spring, cpmposite spring,gas spring, mould spring, deformed spring and other precision spring tensile, compression, disp lacement and rigidity test and analysis.

Standards

GB/T, ASTM, DIN, JIS and other international standards.

Parameters:

Model	TLS-10 TLW-10	TLS-20 TLW-20		TLS-50 TLW-50	TLS-100 TLW-100		TLS-200 TLW-200		TLS-300 TLW-300
Structure	Double Column Type Double space models
Control Method	Digital display/computer control
Load Accuracy	Class1/Class0.5
Load Range	2%~100%F·S
Test force relative error value	≤±1%%
Displacement relative error value	≤±1%
Displacement display resolution	0.01mm
Deformation indication error	≤±(50+0.15L)um
Speed range(mm/min)	0.01-500	0.01-500	0.01-500		0.01-500	0.01-500		0.01-500
Speed relative error	≤±1%
Tensile test space	670	670	770		650	700		700
Compression space	670	670	770		650	700		700
Upper and lower pressure plate parallelism	≤0.05mm
Power Supply	AC220V±10%,50Hz

Application

Application

This series material testing machine product group was primarily developed for standardized tests on ma- terials and components. Used in conjunction with the intuitive HKtest software. Test Typical: wide range of tension, compression, bending, shearing and low cycle test, include metal, building components, rubber, plastic, spring, high strength steel (HSS), aerospace and automotive structures, screws, nuts,large fasteners, wood products etc.

Please contact KASON directly for best quotation
