PUTF305 Doppler Portable Ultrasonic Flow Meter Waste Water

Name: PUTF305 Doppler Portable Ultrasonic Flow Meter Waste Water
Brand: PANDA
Price: USD $1 - 1000 / Piece

FOB Price

USD $1 - $1000 / Piece

1 Piece(Min.Order)

Supply Ability 1000 Piece / Pieces per Month
Port SHANGHAI PORT
Payment Terms:T/T L/C D/P D/A Credit Card PayPal Cash Escrow Other
Delivery Detail:7 days

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:

PANDA

Place of Origin:

China

Model Number:

100

Product Description

PUTF305 Digital Portable Doppler Ultrasonic Flow Meter

Summary

PUDF305 Doppler portable ultrasonic flow meter is designed for measuring liquid with suspended solids, air bubbles or sludge in a sealed closed pipeline. Non-invasive transducers are mounted outside surface of the pipe. It has advantage that measurement is not influenced by pipe scale or blockage. It’s simple to install and calibrate due to unnecessary pipe cutting or flow stop.

Features

l Chargeable Lithium Battery Can Continuously Work For 50 Hours
l Non-invasive Installation, Unnecessary pipe cutting or flow interruption, Acceptable Media Temperature Up To 260℃
l Measuring Accuracy ±0.5% to ±2.0%F.S
l Signal Automatic Gain Adjustment
l Anti-interference to Frequency Converter
l Simple Operation, Only Set Inner Diameter To Realize Flow Measurement
l 2*8 LCD Display Flow Rate, Volume, Velocity etc.

Specification

Transmitter

Measuring Principle	Doppler Ultrasonic
Velocity	0.05- 12 m/s, Bi-directional Measurement
Repeatability	0.4%
Accuracy	±0.5% ~±2.0%F.S
Response Time	2-60s(Select by user)
Measuring Cycle	500ms
Suitable Fluid	Liquid containing more than 100ppm of reflector( suspended solids or air bubbles), reflector >100 micron
Power Supply	AC: 85-265V Built-in lithium battery continuously work for 50 hours
Installation	Portable
Protection Class	IP65
Operating Temperature	-40℃ ~ 75℃
Enclosure Material	ABS
Display	2X8 LCD, 8 digits flow rate, volume (resettable)
Measuring Unit	Volume/mass/velocity: liter, m³, kg, meter, gallon etc Flow time unit: second, minute, hour, day Volume Rate:E-2~E+6
Communication Output Keypad	4~20mA, OCT 6 buttons
Size	270246175mm
Weight	3kg

Transducer

Protection Class	IP67
Fluid Temperature	Std. transducer : -40℃~85℃(Max.120℃)
Fluid Temperature	High Temp : -40℃~260℃
Pipe Size	40mm~6000mm
Transducer Type	General standard
Transducer Material	Std. Aluminum alloy, High Temp.(PEEK)
Cable Length	Std. 5m (customized)
