Industrial vacuum loader factory Sale Various Widely Separate Type plastic Hopper autoloader

Name: Industrial vacuum loader factory Sale Various Widely Separate Type plastic Hopper autoloader
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

Title goes here.

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for
producing PET plastic containers and bottles in all shapes.

Features:

* With a lower suction design, it has a cyclone baffle and separate dust bucket under the filter, which can effectively reduce the load of the filter; * Separate dust bucket for easy dust removal; * With the electrical control function of the two-ingredient proportional valve, it can be directly equipped with a two-ingredient proportional valve; * The hopper loaders above 5HP are equipped with a vacuum breaking valve, which can effectively increase the suction capacity; * The main machine is equipped with fault and motor overload indicator lights, which can give an alarm quickly; * The central operation panel can be used to centrally set the suction parameters of each station; * The main machine is equipped with a suction overtime and fan overload alarm device.

Scope of application:

* Providing high-pressure vacuum (negative pressure) power, it is mainly used in the central feeding system or single-machine feeding applications. The start of the fan in the central feeding system can be connected to and controlled by the centralized control station; * It can be used together with different types of hopper loaders based on customer needs to meet the feeding and conveying of granules and powder; * The suction mode of the feeding system can be equipped with a hopper loader to form a feeding loop.

Schematic diagram:

Specification table:

Model	High pressure fan power (KW)	Conveying capacity (kg/h)	Hopper capacity (L)	Air suction port diameter (mm)	Material suction port diameter (mm)	Voltage
LSAL-2HP-UG	1.5	500	12	38	38	3¢, 400V, 50Hz
LSAL-5HP-UG	3.75	1000	25	50.8	50.8	3¢, 400V, 50Hz
LSAL-10HP-UG	7.5	1600	50	63	63	3¢, 400V, 50Hz
LSAL-5HP-UG-2	3.75	1000	25	50.8	50.8	3¢, 400V, 50Hz
LSAL-10HP-UG-2	7.5	1600	50	63	63	3¢, 400V, 50Hz
LSAL-5HP-UG-4	3.75	1000	25	50.8	50.8	3¢, 400V, 50Hz
LSAL-10HP-UG-4	7.5	1600	50	63	63	3¢, 400V, 50Hz
Conveying capacity reference: horizontal - 4 meters, vertical - 4 meters, raw material - ABS granules; bulk density - 0.65kg/L
