300kg/h good quality plastic vacuum feeder
- 200 Set / Sets per Month
- Guangzhou
- T/T L/C D/P D/A Credit Card
- Multi-station Vacuum Plastic auto Loader Suction Machine Price
- vacuum hopper loader plastic pellet auto loader price
- plastic vacuum autoloader for plastic pellet feeding machine
- Euro Plastic Vacuum Loader Suction Machine Feeding Machine Feeder Autoloder
- Euro Automatic plastic vacuum loader for granule pellet
- High Quality Separate Type Hopper Loader Plastic pellets Vacuum Hopper Loader Industrial material auto loader
Product Details
Condition: | New | Application: | material loader | Place of Origin: | Guangdong, China |
Brand Name: | LongHe | Model Number: | AS-300G | Voltage: | 230V |
Power(W): | 950W | Dimension(L*W*H): | 400x360x600mm | Weight: | 11kg |
Certification: | ISO9001 | Warranty: | One year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Plastic Vacuum Feeder
APPLICATION AND PROPERTIES:
1, Vacuum Feeding Machine is applicable for conveying raw materials and granulated materials for avoiding pollution.
2, It features microcomputer control, simple operation and easy repair, and may automatically alarm when there isn’ t material.
3, Stainless steel material chamber door for protecting the materials from pollution, independent filtering device.
4,Convenient for removing dust, adopt double elecrtic-eye switch to control the feeding action (optional), motor protective device, filter observing window.
5,Two-Material Proportional Valve is optional for mixing new material with granulated material or immediately recycling granulated material.
TECHNICAL PARAMETERS:
Model | AS-300G | AS-400G | AS-700G | AS-800G | AS-800G2 | ||
Motor power(w) | Type | Carbon Brush Type | Induction Type | Carbon Brush Type | Induction Type | Induction Type | |
Specification | 950 | 750 | 950 | 750 | 1500 | ||
Voltage Specification | 1Φ,230v,50HZ | 3Φ,400v,50HZ | 1Φ,230v,50HZ | 3Φ,400v,50HZ | 3Φ,400v,50HZ | ||
Material Feeding Capacity(kg/h) | 300 | 400 | 300 | 400 | 550 | ||
Suction Lift(M) | 4 | 4 | 4 | 4 | 4 | ||
Static Air Pressure(MAX) | 1500mm/HZO | 1800mm/HZO | 1800mm/HZO | 1800mm/HZO | 2400mm/HZO | ||
Storage Tank Capacity(L) | 6 | 10 | 7.5 | 7.5 | 10 | ||
Internal Diameter of Conveying Pipe(mm) | Φ38 | Φ38 | Φ38 | Φ38 | Φ38 | ||
Overall Diamension(mm) | Hopper | / | / | 370x300x550 | 460x380x550 | 460x380x700 | |
Main Unit | 400x360x600 | 400x300x500 | 400x300x440 | 400x300x440 | 400x300x500 | ||
Weight(kg) | 11 | 28 | 25 | 55 | 65 |
