LTE Cat-M NB-IoT Module SIM7080G Low-speed Low-power LTE LPWA Module
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1999
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
LTE Cat.1 10Mbps/5Mbps 4G Development Core Board GSM LTE GNSS Module SIMCom A7670SANegotiableMOQ: 1 -
New Generation 900MHz WiFi 802.11ah Module Low Power Long Range IoT WiFi Halow ModuleNegotiableMOQ: 1
-
16x24x3mm 802.11 B/g/n 2.4GHz 2.4G WiFi Module ESP-12ENegotiableMOQ: 1
-
BT4.0 Quad-band GSM/GPRS/GNSS Module MC60NegotiableMOQ: 1
-
4M/8M/16M Flash ESP32-WROVER-IE BT WiFi Module ESP32-WROVER-ENegotiableMOQ: 1
Description
SIM7080G
CAT-M&NB-IoT Module
The SIM7080G is Multi-Band CAT-M and NB-IoT module solution in a SMT type .
It has strong extension capability with rich interfaces including UART, GPIO, PCM, SPI, I2C etc. The module provides much flexibility and ease of integration for customer's application.
It is designed for applications that need low latency, Low throughput data communication in a variety of radio propagation conditions. Due to the unique combination of performance, security and flexibility, the SIM7080G module is ideally suited for M2M applications, such as metering, asset tracking, remote monitoring , E-health etc..
Product Advantages
• With Power Saving Mode(PSM) and Extended Discontinuous Reception(eDRX), SIM7080G can extend battery life to 10 years.
• CAT-M, NB-IoT dual mode
• The package of SIM7080G is compatible with SIM868
General Features |
Interfaces |
Support Bands: CAT-M: B1/B2/B3/B4/B5/B8/B12/B13/B14/B18/B19/B20/B25/B26 /B27/B28/B66/B85 CAT-NB: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B28 /B66/B71/B85 LTE RF Power Class: 5 (Typ. 21dbm) Control Via AT Commands Supply voltage range: 2.7V-4.8V Operation temperature: -40°C to +85°C Dimensions: 17.6 X 15.7 X 2.4 mm Weight: 1.4g±0.2g |
UART SIM card PCM/I2S/SPI I2C GPIO ADC USB Embedded SIM (optional) |
Data |
Other Features |
Cat-M: Uplink: 1119Kbps Downlink:589Kbps NB-IoT: Uplink: 150Kbps Downlink:136Kbps |
TCP/UDP HTTP/HTTPS/TLS/DTLS/PING/LWM2M/COAP/MQTT Ayla Cloud Firmware update via USB FOTA EAT |
Consumption |
Certifications(plan) |
PSM: 3.2uA Sleep: 0.6mA @PTW=40.96s eDRX=81.92s Idle: 10mA |
RoHSREACHJATETelecDocomoKDDISoftbankRCMCE(RED)GCFDeutsche TelekomFCCPTCRBAT&TVerizonT-MobileUS CellularIC |
