SIMCOM SIM7600SA 4G LTE Module SIM7600SA-H

SIMCOM SIM7600SA 4G LTE Module SIM7600SA-H thumbnail-1
SIMCOM SIM7600SA 4G LTE Module SIM7600SA-H thumbnail-2
SIMCOM SIM7600SA 4G LTE Module SIM7600SA-H photo-1
SIMCOM SIM7600SA 4G LTE Module SIM7600SA-H photo-2
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1999
Annual Export Value:
US$50 Million - US$100 Million
Contact Supplier Request Quote Chat Now
Shenzhen Hurryup Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Description
SIM7600X-H-PCIE LTE CAT.4
The SIM7600-H-PCIE series integrates multiple satellite high accuracy positioning GNSS systems, with multiple built-in network protocols, supports drivers for main operation systems (USB driver for Windows, Linux and Android etc.) and software function, AT commands are compatible with SIM7500/SIM7600 series modules. Meanwhile the SIM7600-H-PCIE series integrates main industrial standard interfaces, with powerful expansibility, including abundant interfaces such as UART, USB, GPIO, which is suitable for main IoT applications such as telematics, surveillance devices, CPE, industrial routers, and remote diagnostics etc.

Product Advantages ● Mini-PCIE interface with strong compatibility ● Suitable for LTE, UMTS and GSM networks with global coverage ● Abundant software functions: FOTA, LBS, TLS, VoLTE ● Multi-constellation GNSS receiver support ● AT commands of the SIM7600-H-PCIE series are compatible with the SIM7500/SIM7600 series modules


Product Details
Product
SIM7600A-H
SIM7600V-H
SIM7600SA-H
SIM7600JC-H
SIM7600E-H
SIM7600NA-H
SIM7600G-H
Form Factor
Mini PCIE
Mini PCIE
Mini PCIE
Mini PCIE
Mini PCIE
Mini PCIE
Mini PCIE
Dimensions(mm)
50.8*31*5.35
50.8*31*5.35
50.8*31*5.35
50.8*31*5.35
50.8*31*5.35
50.8*31*5.35
50.8*31*5.35
Frequency Bands
LTE-FDD
B2/B4/B12
B2/B4/B5/B13
B1/B2/B3/B4/B5/
B7/B8/B20/B28/B66
B1/B3/B8/B18/B19/B26
B1/B3/B5/B7/B8/B20
B2/B4/B5/B12/B13/
B14/B25/ B26/B66/B71
B1/B2/B3/B4/B5/
B7/B8/B12/B13/
B18/B19/B20/B25/
B26/B28/B66
LTE-TDD
B40
B38/B40/B41
B41
B34/B38/B39/
B40/B41
WCDMA
B2/B5
B1/B2/B5/B8
1/B5/B8
B1/B2/B4/B5/
B6/B8/B19
GSM
850/900/1800/1900MHz
900/1800MHz
850/900/1800/1900MHz
GNSS
o
o
o
o
o
o
o
Temperature
-40℃ ~ +85℃
-40℃ ~ +85℃
-40℃ ~ +85℃
-40℃ ~ +85℃
-40℃ ~ +85℃
-40℃ ~ +85℃
-40℃ ~ +85℃
Electrical Features
Supply Voltage(V)
3.0~ 3.6
3.0~ 3.6
3.0~ 3.6
3.0~ 3.6
3.0~ 3.6
3.0~ 3.6
3.0~ 3.6
Power Consumption(mA)
LTE
2.3
2.3
2.3
2.3
2.3
2.3
2.3
WCDMA,
DRX=9
3.3
3.3
3.3
3.3
GSM,BS_PA_MFRMS=2
2.8
2.8
2.8
Data Transfer
LTE(Mbps)
150(DL)/50(UL)
150(DL)/50(UL)
150(DL)/50(UL)
150(DL)/50(UL)
150(DL)/50(UL)
150(DL)/50(UL)
150(DL)/50(UL)
HSPA+(Mbps)
42(DL)/5.76(UL)
42(DL)/5.76(UL)
42(DL)/5.76(UL)
42(DL)/5.76(UL)
WCDMA(Kbps)
384(DL)/384(UL)
384(DL)/384(UL)
384(DL)/384(UL)
384(DL)/384(UL)
GPRS/EDGE(Kbps)
236.8(DL)/236.8(UL)
236.8(DL)/236.8(UL)
236.8(DL)/236.8(UL)
Software Features
Protocol
TCP/IP/IPV4/IPV6/
Multi-PDP/FTP/FTPS/
HTTP/ HTTPS/DNS
TCP/IP/IPV4/IPV6/
Multi-PDP/FTP/FTPS/
HTTP/ HTTPS/DNS
TCP/IP/IPV4/IPV6/
Multi-PDP/FTP/FTPS/
HTTP/ HTTPS/DNS
TCP/IP/IPV4/IPV6/
Multi-PDP/FTP/FTPS/
HTTP/ HTTPS/DNS
TCP/IP/IPV4/IPV6/
Multi-PDP/FTP/FTPS/
HTTP/ HTTPS/DNS
TCP/IP/IPV4/IPV6/
Multi-PDP/FTP/FTPS/
HTTP/ HTTPS/DNS
TCP/IP/IPV4/IPV6/
Multi-PDP/FTP/FTPS/
HTTP/ HTTPS/DNS
TLS
●
●
●
●
●
●
●
File System
●
●
●
●
●
●
●
Audio Record/Play
o
o
o
o
o
o
o
TTS
o
o
o
o
o
o
o
DTMF
o
o
o
o
o
o
o
LBS
●
●
●
●
●
●
●
FOTA
●
●
●
●
●
●
●
Jamming Detection
●
●
●
●
●
●
●
Android RIL
Android 5.0/6.0/7.0/8.0/9.0
Android 5.0/6.0/7.0/8.0/9.0
Android 5.0/6.0/
7.0/8.0/9.0
Android 5.0/6.0/
7.0/8.0/9.0
Android 5.0/6.0/
7.0/8.0/9.0
Android 5.0/6.0/
7.0/8.0/9.0
Android 5.0/6.0/
7.0/8.0/9.0
USB Driver
Microsoft Windows 7/8/10
Linux/Android
Microsoft Windows 7/8/10
Linux/Android
Microsoft Windows
7/8/10
Linux/Android
Microsoft Windows
7/8/10
Linux/Android
Microsoft Windows
7/8/10
Linux/Android
Microsoft Windows
7/8/10
Linux/Android
Microsoft Windows
7/8/10
Linux/Android
WWAN (RNDIS)
●
●
●
●
●
●
●
ECM
●
●
●
●
●
●
●
MBIM
Win8/Win10
Win8/Win10
Win8/Win10
Win8/Win10
Win8/Win10
Win8/Win10
Win8/Win10
NDIS
Linux/Windows 7/8/10
Linux/Windows 7/8/10
Linux/Windows 7/8/10
Linux/Windows 7/8/10
Linux/Windows 7/8/10
Linux/Windows 7/8/10
Linux/Windows 7/8/10
Open Linux
o
o
o
o
o
o
o
Firmware Upgrade
USB/FOTA
USB/FOTA
USB/FOTA
USB/FOTA
USB/FOTA
USB/FOTA
USB/FOTA
Interfaces
SIM Card
1.8V/3.0V
1.8V/3.0V
1.8V/3.0V
1.8V/3.0V
1.8V/3.0V
1.8V/3.0V
1.8V/3.0V
UART
●
●
●
●
●
●
●
USB
●
●
●
●
●
●
●
PCM
o
o
o
o
o
o
o
Analog Audio
o
o
o
o
o
o
o
Embedded SIM card socket
o
o
o
o
o
o
o
Diversity Receiver
●
●
●
●
●
●
●
Certification
Regulatory
FCC/PTCRB/IC/
RoHS/ REACH
FCC/GCF/
RoHS/REACH
CE-RED/ACMA/FCC/NCC/
RoHS/REACH/Anatel
Telec/JATE/
RoHS/REACH
CE-RED/RoHS/
REACH/ IMDA/GCF
FCC*/IC*/PTCRB*/
GCF*/ RoHS*/REACH*
CE-RED/FCC/IC/RCM/
RoHS*/ REACH*
Carrier
AT&T
Verizon
Docomo/Softbank
Deutsche Telekom
/Vodafone
AT&T*/Verizon*/
Sprint*/T-mobile*
●: support         o: optional         * : on going
Why Choose Us
FAQ
Q1. What is the minimum order quantity for your products? A1. Minimum order quantity starts from ONE piece. Q2. What's the quality of your products? A2. We have professional QA/QC team to ensure the quality before shipment. We provide 1 year warranty for all the new and original products. Q3. Is this product free of shipping or free samples? A3. Regularly the sample and shipping cost will be at the buyer's account. But in specific case, we may take these costs. Please kindly check with us the details by email. Thank you.
