Lower Cost 4G Cat1 SIM7500E Multi-band LTE-FDD/EDGE/GSM/GPS/GNSS Module With LGA/Mini-PCIE Interface

Lower Cost 4G Cat1 SIM7500E Multi-band LTE-FDD/EDGE/GSM/GPS/GNSS Module With LGA/Mini-PCIE Interface thumbnail-1
Lower Cost 4G Cat1 SIM7500E Multi-band LTE-FDD/EDGE/GSM/GPS/GNSS Module With LGA/Mini-PCIE Interface photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1999
Annual Export Value:
US$50 Million - US$100 Million
Contact Supplier Request Quote Chat Now
Shenzhen Hurryup Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Description


• The SIM7500E is Multi-Band LTE-FDD/GSM module solution in a LGA type which supports LTE CAT1 up to 10Mbps for downlink data transfer.

• It has strong extension capability with rich interfaces including UART, USB2.0, I2C, GPIO etc. With abundant application capability like TCP/ UDP/ FTP/ FTPS/ HTTP/ HTTPS/ SMTP/ POP3 and MMS, the module provides much flexibility and ease of integration for customer's application.

General features
• FDD-LTE B3/B7/B20
• GSM/GPRS/EDGE 900/1800 MHz
• Control Via AT Commands
• Supply voltage range: 3.4V~ 4.2V
• Operation temperature: -40℃ to +85℃
• Dimension: 24*27*2.75mm
• Weight: 4.0g
• GNSS gpsOne Gen 8B;standalone;assisted,XTRA

Specifications for Data transfer
• LTE CAT1
- Uplink up to 5Mbps,
- Downlink up to 10Mbps
• EDGE Class
- Uplink up to 236.8Kbps,
- Downlink up to 236.8Kbps
• GPRS
- Uplink/Downlink up to 85.6Kbps
• CSD
- GSM data rate 14.4Kbps

Other features
• USB Driver for Microsoft Windows 2000/XP/Vista/Win7/Win8
• USB Driver for Windows CE/Mobile
• USB Driver for Linux /Android
• RIL supporting for Android/Windows CE/Mobile
• Automatic installation for windows
• Linux API SDK
• Firmware update via USB
• TCP/IP/IPV4/V6 Multi-PDP,MT PDP
• FTP/FTPS/HTTP/HTTPS/SMTP/POP3/DNS/MMS
• DTMF
• MBIM to Win8
• Source code of the PC manager of the device for reference

Interfaces
• USB2.0
• UART
• SIM card
• I2C
• GPIO
• ADC
• PCM

Certifications(Plan)
• CE
• ROHS
• REACH
Why Choose Us
FAQ
Q1. What is the minimum order quantity for your products? A1. Minimum order quantity starts from ONE piece. Q2. What's the quality of your products? A2. We have professional QA/QC team to ensure the quality before shipment. We provide 1 year warranty for all the new and original products. Q3. Is this product free of shipping or free samples? A3. Regularly the sample and shipping cost will be at the buyer's account. But in specific case, we may take these costs. Please kindly check with us the details by email. Thank you.
