MeiG MG261 Smart AI Module Support Dual Cameras

MeiG MG261 Smart AI Module Support Dual Cameras thumbnail-1
MeiG MG261 Smart AI Module Support Dual Cameras thumbnail-2
MeiG MG261 Smart AI Module Support Dual Cameras photo-1
MeiG MG261 Smart AI Module Support Dual Cameras photo-2
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1999
Annual Export Value:
US$50 Million - US$100 Million
Contact Supplier Request Quote Chat Now
Shenzhen Hurryup Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Description
Product Description
● MG261 is an AI module launched by MeiG Smart. It adopts HiSilicon chipset and embeds an AI software.

● As an smart module dedicated to the IoT industry, MG261 integrates a new generation of ISP, adopts the latest H.265 video compression encoder, and integrates a high-performance NNIE engine, leading the industry in its low bit rate, high quality, intelligent processing and analysis, low power consumption, etc.

● MG261 module has built-in DDR, EMMC with LCC packaging and provides multiple software and hardware interfaces, which greatly reduces the R&D costs of customers, and can be widely used in various industries such as security, vehicle and new retail.

Main advantages:
● integrated neural network acceleration engine, handling performance 1Tops
● support for h. 265 codec
● support dual 1080P@30FPS camera
● built-in ISP supports WDR and supports 6-dof Support external 1080P display screen, and support HDMI output
● support hardware AES/DES and other encryption Audio input/output support
● support USB,SDIO3.0,RMII and other common interface
Basic Attributes:
Product model:
MG261 Module
Packaging:
LCC package (140pin+LGA 40pin)
Size:
38.0 * 38.0 * 3.0 mm
Weight:
< 8 g
Operating system:
Linux 4.9
Video coding:
H.264/265 codec maximum width 2688, maximum resolution 2688*1944, only support its own coding stream
H.264/ h.265 multi-stream real-time coding (decoding) capability
2688*1536@30fps code +720*480@30fps code +360*240@30fps code
1920*1080@30fps encoding +720*480@30fps encoding +1920*1080@30fps decoding
Support for 8 areas of interest (ROI) coding
AI functions:
Integrated neural network acceleration engine, processing performance up to 1Tops
Integrated intelligent computing acceleration engine (including tracking and face correction)
Integrated face recognition software
Module Interface:
LCD interface: MIPI_TX*1,HDMI*1
Camera: MIPI_RX*2
SDIO * 2
UART * 2
RMII*1, support 100Mbps network card
GPIO * 4
USB2.0 * 1
SPI * 1
I2C * 3
I2S * 1
PCM * 1
PWM * 2
RTC * 1
Dual channel audio output *1
Double channel audio input *1
Certification Information:
CCC/ROHS
Built-in Memory:
Support DDR3, maximum capacity support 16Gbit
Support SPI Nor Flash, maximum support 32MB
Support SPI NAND Flash, up to 4Gbit support
Support for EMMC4.5, support for 4GB/8GB/16GB or greater storage space
Drivers & Tools:
Driver:
Windows XP,Windows 7,Windows 8,Windows 8.1,Windows 10,Linux,Android
Tools:
One-click upgrade tool
FOTA upgrade
Video Interface:
Support two MIPI interface input
The first way supports the input maximum resolution of 2688*1944, and the second way supports the input maximum resolution of 2048*1536
Support 4Lane Mipi interface video output
Support HDMI 1.4 output (maximum resolution 1080p@60fps)
Basic features:
Operating temperature:
- 20 ℃ to 70 ℃
Storage temperature:
- 45 ℃ to 90 ℃
Humidity:
5% ~ 95%
The maximum power consumption is 2087mw, typical TBD
Usage:
Face recognition tablet
Face payment terminal
New retail terminal
The robot
Smart door lock
AI camera
AI computing box
MG261 configuration information:
MG261
Storage:
DDR3:1 gb
EMMC: 8 gb
Face recognition:
support
So:
support
Camera:
2
USB mode:
The HOST
