EC21 LTE Series Cat-1 Module Optimized Specially 4G Module for M2M and IoT Applications EC21-X, EC21-E, EC21-A
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1999
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
EC21 4G LTE Module for IoT/M2M Application EC21-A EC21-E Mini PCIeNegotiableMOQ: 1 -
EC20 R2.1 IoT M2M 4G Module Optimized LTE Cat4 Module, EC20CEFILG Mini PCIe EC20-EC EC20CEFILG-128-SGNSNegotiableMOQ: 1
-
EG21-G 4G Module LGA Package IoT/M2M-optimized LTE Cat 1 Module EG21NegotiableMOQ: 1
-
EC20 CE FILG Mini PCIe LTE Category 4 Module EC20CEFILG-128-SGNS EC20-CENegotiableMOQ: 1
-
EM12-G LTE 4G Module Wireless LTE Cat12 Module EM12 EM12G LTE Module EM12GPA-512-SGADNegotiableMOQ: 1
Description
Overview
EC21 is a series of LTE category 1 module optimized specially for M2M and IoT applications. It features cost-effective, low-power LTE connectivity, and delivers maximum data rates up to 10Mbps downlink and 5Mbps uplink. These make EC21 an ideal solution for numerous IoT applications that are not reliant on high speed connectivity but still require the longevity and reliability of LTE networks.
EC21 is compatible with UMTS/HSPA+ UC20/UC200T modules and multi-mode LTE Standard EC25/EC20 R2.0/EC20 R2.1/EG25-G/EG21-G modules in the compact and unified form factor. It contains 10 variants: EC21-E, EC21-EU, EC21-EUX, EC21-A, EC21-V, EC21-AUT, EC21-AU, EC21-AUX, EC21-KL and EC21-J. This makes it backward-compatible with existing EDGE and GSM/GPRS networks, ensuring that it can easily migrate from LTE to 2G or 3G network.
EC21 supports Qualcomm® IZat™ location technology Gen8C Lite (GPS, GLONASS, BeiDou/Compass, Galileo and QZSS). The integrated GNSS greatly simplifies product design, and provides quicker, more accurate and more dependable positioning.
A rich set of Internet protocols, industry-standard interfaces and abundant functionalities (USB serial drivers for Windows 7/8/8.1/10, Linux, Android/eCall*) extend the applicability of the module to a wide range of M2M and IoT applications such as smart metering, wearable devices, environmental monitoring, asset tracking, fleet management, security and alarm systems, and so on.
Key Benefits
● Cost-effective, lower-power LTE connectivity optimized for broadband IoT applications
● Worldwide LTE, UMTS/HSPA(+) and GSM/GPRS/EDGE coverage
● Multi-constellation GNSS receiver available for applications requiring fast and accurate fixes in any environment
● Feature refinements: supports DFOTA, eCall* and DTMF
● MIMO technology meets demands for data rate and link reliability in modem wireless communication systems(www.hurryup.en.china.cn)
Specification
EC21-E
LTE-FDD: B1/B3/B5/B7/B8/B20
WCDMA: B1/B5/B8
GSM/EDGE: B3/B8
Embedded GNSS: Optional
Wi-Fi Interface: Y
Region: EMEA/Thailand/India
Carrier:
Vodafone/ Deutsche Telekom/
Telefónica*
Regulatory:
GCF/ CE/ FAC
Others:
WHQL
Telefónica*
Regulatory:
GCF/ CE/ FAC
Others:
WHQL
EC21-EU
LTE-FDD: B1/B3/B7/B8/B20/B28A
WCDMA: B1/B8
GSM/EDGE: B3/B8
Embedded GNSS: Optional
Wi-Fi Interface: Y
Region: EMEA/Thailand
Carrier:
Deutsche Telekom Regulatory:
GCF/ CE/ NCC/ RCM
Others:
WHQL
Deutsche Telekom Regulatory:
GCF/ CE/ NCC/ RCM
Others:
WHQL
EC21-EUX
LTE-FDD: B1/B3/B7/B8/B20/B28A
WCDMA: B1/B8
GSM/EDGE: B3/B8
Embedded GNSS: Optional
Wi-Fi Interface: Y
Region: EMEA/Thailand
Regulatory:
CE/ RCM/ GCF*/
Others:
WHQL
CE/ RCM/ GCF*/
Others:
WHQL
EC21-A
LTE-FDD: B2/B4/B12
WCDMA: B2/B4/B5
GSM/EDGE: /
Embedded GNS: Optional
Wi-Fi Interface: Y
Region: North America
Carrier:
AT&T/ U.S. Cellular/
T-Mobile/
Rogers/ Telus
Regulatory:
FCC/ PTCRB/ IC
Others:
WHQL
AT&T/ U.S. Cellular/
T-Mobile/
Rogers/ Telus
Regulatory:
FCC/ PTCRB/ IC
Others:
WHQL
EC21-V
LTE-FDD: B4/B13
WCDMA: /
GSM/EDGE: /
Embedded GNSS: Optional
Wi-Fi Interface: Y
Region: Verizon
Carrier:
Verizon
Regulatory:
GCF/ FCC
Others:
WHQL
Verizon
Regulatory:
GCF/ FCC
Others:
WHQL
EC21-AUT
LTE-FDD: B1/B3/B5/B7/B28
WCDMA: B1/B5
GSM/EDGE: /
Embedded GNSS: Optional
Wi-Fi Interface: Y
Region: Australia
Carrier:
Telstra
Regulatory:
GCF/ RCM
Others:
WHQL
Telstra
Regulatory:
GCF/ RCM
Others:
WHQL
EC21-AU
LTE-FDD: B1/B2①/B3/B4/B5/B7/B8/B28
LTE-TDD: B40
WCDMA: B1/B2/B5/B8
GSM/EDGE: Quad-band
Embedded GNSS: Optional
Wi-Fi Interface: Y
Region: Latin America/Australia/ New Zealand
Carrier:
Telstra
Regulatory:
FCC/ IC/ Anatel/ NCC/ JATE/ TELEC/ RCM
Others:
WHQL
Telstra
Regulatory:
FCC/ IC/ Anatel/ NCC/ JATE/ TELEC/ RCM
Others:
WHQL
EC21-AUX
LTE-FDD: B1/B2①/B3/B4/B5/B7/B8/B28
LTE-TDD: B40
WCDMA: B1/ B2/ B5/ B8/ B4
GSM/EDGE: Quad-band
Embedded GNSS: Optional
Wi-Fi Interface: Y
Region: Latin America/Australia/ New Zealand
Regulatory:
CE/ FCC/ Anatel/ NCC/ RCM
Others:
WHQL
CE/ FCC/ Anatel/ NCC/ RCM
Others:
WHQL
EC21-KL
LTE-FDD: B1/B3/B5/B7/B8
LTE-TDD: /
WCDMA: /
GSM/EDGE: /
Embedded GNSS: N
Wi-Fi Interface: Y
Region: South Korea
Carrier:
KT/ SKT
Regulatory:
KC
Others:
WHQL
KT/ SKT
Regulatory:
KC
Others:
WHQL
EC21-J
LTE-FDD: B1/B3/B8/B18/B19/B26
LTE-TDD: /
WCDMA: /
GSM/EDGE: /
Embedded GNSS: N
Wi-Fi Interface: Y
Region: Japan
Carrier:
NTT DOCOMO/ KDDI
Regulatory:
JATE/ TELEC
Others:
WHQL
NTT DOCOMO/ KDDI
Regulatory:
JATE/ TELEC
Others:
WHQL
Notes:
① LTE-FDD B2 of EC21-AU and EC21-AUX does not support Rx-diversity.
* Under development
① LTE-FDD B2 of EC21-AU and EC21-AUX does not support Rx-diversity.
* Under development
