Heat Resisting Stainless Steel Filter Element for Paraffin Filtration

Anping Dongjie Wire Mesh Products Co., Ltd.
Heat Resisting Stainless Steel Filter Element for Paraffin Filtration thumbnail-1
Heat Resisting Stainless Steel Filter Element for Paraffin Filtration thumbnail-2
Heat Resisting Stainless Steel Filter Element for Paraffin Filtration thumbnail-3
Heat Resisting Stainless Steel Filter Element for Paraffin Filtration thumbnail-4
Heat Resisting Stainless Steel Filter Element for Paraffin Filtration thumbnail-5
Heat Resisting Stainless Steel Filter Element for Paraffin Filtration photo-1
Heat Resisting Stainless Steel Filter Element for Paraffin Filtration photo-2
Heat Resisting Stainless Steel Filter Element for Paraffin Filtration photo-3
Heat Resisting Stainless Steel Filter Element for Paraffin Filtration photo-4
Heat Resisting Stainless Steel Filter Element for Paraffin Filtration photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
2002
Annual Export Value:
US$10 Million - US$50 Million
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us

heat resisting stainless steel filter element for paraffin filtration

Heat resisting stainless steel filter element for paraffin filtration



Model Number

Stainless steel filter element

Filter fineness

1-200um

Brand

Dongjie

Material

Stainless steel sintering network

Specification

5-40inches(or as your request)

Working temp

0.1-30MPa

OEM

Yes

Sample

By free

Loading Port

Tianjin

Payment

L/C,T/T ,West Union

Package

With bubble wrapping paper, packaged in wooden boxes. Or according client'srequirement.

Delivery Time

15-20 days

Heat resisting stainless steel filter element for paraffin filtration

Heat resisting stainless steel filter element for paraffin filtration

TYPE : PF-D/L-R , PF- Filter Element, D-Diameter, L-Length, R-Resolution

TYPE

L(mm)

D(mm)

M

Filter area

R (μm)

Material

PF-86/200-R

200

86

M65x2P

0.20M2

3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75

stainless steel fiber felt, Stainless steel woven mesh

PF-86/350-R

350

0.35M2

PF-86/500-R

500

0.50M2

PF-100/800-R

800

100

M80x2P

1.00M2

TYPE

L
(mm)

D
(mm)

M

Filter area

R(μm)

Material

PF-65/250-R

250

65

226
223
220
215

0.135M2

3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75

stainless steel fiber felt, Stainless steel woven mesh

PF-65/500-R

500

0.38M2

PF-70/750-R

750

70

0.42M2

PF-70/750-R

750

70

0.60M2



TYPE

L
(mm)

D
(mm)

M

Filter area

R(μm)

Material

PF-35/102-R

102

35

M18
M20x2.5
M20x1.5
NPT1"
3/4-16

0.026M2

3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75

stainless steel fiber felt, Stainless steel woven mesh

PF-35/207-R

207

0.07M2

PF-35/210-R

210

0.07M2

PF-35/242-R

242

0.08M2

PF-35/425-R

425

0.15M2

PF-35/485-R

485

0.20M2



TYPE

L
(mm)

D
(mm)

M

Filter area

R(μm)

Material

PF-62/180-R

180

62

G1"

0.09M2

3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75

stainless steel fiber felt, Stainless steel woven mesh

PF-86/254-R

254

86

G2"

0.17M2

PF-86/381-R

381

0.20M2

PF-86/508-R

508

0.27M2

PF-86/760-R

760

0.58M2

PF-140/760-R

760

140

0.65M2

TYPE

L
(mm)

D
(mm)

M

Filter area

R(μm)

Material

PF-60/1432-R

1432

60

2"x12UN-2A

1.015M2

3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75

stainless steel fiber felt, Stainless steel woven mesh

PF-60/1241-R

1241

0.98M2

PF-60/1025-R

1025

0.81M2



TYPE

L
(mm)

D
(mm)

M

Filter area

R(μm)

Material

PF-60/400-R

400

60

M33x1.5P
M33x2P

0.40M2

3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75

stainless steel fiber felt, Stainless steel woven mesh

PF-60/500-R

500

0.50M2

PF-60/1000-R

1000

1.00M2



Feature

1.High dirt holding capacity, high filtering accuracy, longer on stream life

2.Corrosion resistance of nitric acid, alkali, and organic solvent proof.It can be used for a long period of service in the temperature of 600 degree

3.High porosity and excellent permeability which results in low pressure drop and large flow

4.Pleatable, provide a large filter area, and can be welded and machined

5.Cleanable, can be for used many times

  Heat resisting stainless steel filter element for paraffin filtration

Usages

1. Polyester melt purification in chemical fiber and membrane industries

2. High temperature filtration and corrosion liqiud filtration in petroleum industry.

3. Hydraulic fuel and lubrication oil filtration in mechanical equipment

4. Liquid purification in pharmaceutical, biological and beverage industries.





 Heat resisting stainless steel filter element for paraffin filtration



Heat resisting stainless steel filter element for paraffin filtration

 Heat resisting stainless steel filter element for paraffin filtration
