loop cutting machine
this machine employs microcomputer controller to set belt cutting length , the knife is added with adhesive Tape Hook and Loop/ Magic Tape Belt Cutting Machineeaters for hot cutting so that the cut edge can be heated and solidified without burrs, the machine is ergonomically designed . Operation is easy .
Applications :
sizing cutting for PP belt , Nylon belt , woven belt and elastic band , etc ...
| Model | Voltage | Power | G.W.(KW) | N.W.(KW) |
| DP-160A loop cutting machine | 110V 220V |
1/4HP | 90kgs | 125kgs |
| Cutting Length | Cutting Width | Measurement | ||
| 0.1-9999.9mm | 1-160mm | 600x700x1000mm | ||
| Model | Voltage | Power | NW | GW |
| KG | KG | |||
| DP-101loop cutting machine | 110 V / 220 V | 1 / 2 HP | 80 | 150 |
| Volume | Slice length | Slice width | Feeding speed | |
| (LxWxH cm) | Min. ~ Max. (mm) | (mm) | (mm / min) | |
| 65 x 80 x 120 | 1 ~ 10000 | 1 ~ 160 | 20000 ~ 120000 |
Full computer and temperature control.
Steady heat control.
Easy operation and low material lost.
One time sealing and cutting operation.
Wire cutting function.
Square cutting shape.
Application:
Precision cutting of webbing, nylon, woven fabrics, stretch, safety belts, elastic webbing, stretch webbing, ribbon, color webbing, polyester webbing, belt webbing, cotton webbing, textiles and plastics.
automatic webbing belt cutting machine application :
