Home > Manufacturing & Processing Machinery > Machine Tools > Punching Machine > Membrane Switch Press Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
2000
Annual Export Value:
US$1.5 Million - US$2.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Max Working Area 650x600mm Automatic Die Cutting and Creasing MachineNegotiableMOQ: 1 -
Hydraulic Press Die Cutting Machine Rolled Rubber Material Foam Die Cutting Press MachineNegotiableMOQ: 1
-
Rubber Mat Making Machine Plastic Gasket Making Machine With Technical After Sale Service ProvidedNegotiableMOQ: 1
-
Automatic Roll to Roll Large Die Cutter for Foam Fabric Cotton Leather Material Hydraulic Punching Press Die Cutting MachineNegotiableMOQ: 1
-
50 Ton Label Die Cutting Kiss Cut Full Cut EVA Hole Punching MachineNegotiableMOQ: 1
Main Technical Parameters | ||||||||||||||
ITEM NO. | Capacity | table-board underneath size | Press base size | Table height | HORSE POWER | Max spacing | Max range | |||||||
TON | mm | mm | mm | HP | mm | mm | ||||||||
DP-650 | 40 | 600*650 | 600*650 | 110 | 7.5 | 100 | 100 | |||||||
accuracy | Machine size | Packing size | CBM | weight | Gross weight | |||||||||
±0.01mm | 1320X1200X1900mm | 1.6X1.4X2.1 M3 | 4.7M3 | 2 ton | 2.5Ton | |||||||||
Configuration Detail | ||||||||||||||
l PLC 1 Set Mitsubishi | ||||||||||||||
l Touch Screen 1 Set Shanghai EV | ||||||||||||||
l Safety Photoelectric 1 Set Taiwan | ||||||||||||||
l Automatic Depth Adjustment Motor 1 Set Taiwan | ||||||||||||||
l Main Motor (7.5KW-4) 1 Set QL Taiwan | ||||||||||||||
l Oil Pump 1 Set Danxin Taiwan | ||||||||||||||
l Magnetic Valve 1 Group Danxin Taiwan | ||||||||||||||
l Main engine Oil Cylinder 1 Set Self-production | ||||||||||||||
l Feeding Oil System Cylinder 1 Set Self-production | ||||||||||||||
l Air Cooling System 1 Set Self-production | ||||||||||||||
l Oil Seal 1 Set Japan | ||||||||||||||
l Feed Plate Slippery Course 2 Bar HIWINSH | ||||||||||||||
l PE Plate(10mm) 1 Piece Made in China | ||||||||||||||
DP-650P Kraft Paper /Firepoof Paper Cutting Machine
Sheet Material Hydraulic Die Cutting Machine
Functional characteristics:Template launch deveice under the belt ,easy and flexible operation;
Electronic positioning ,precision and accurate,and the precision and accuracy cann be controlled in 0.01 to 0.03mm ,push board
back forth precision can be controlled in 0.02 to 0.05mm.
There is shockproof board installed at under-chassis ,therefore ,the machine body is stable and reliable.
Applies to punch electronic materials such as aluminum foil ,PET ,protective film through cutting or kiss cutting ,all kinds of
precision components of stamping forming.
PLC +man-machine automatic programming control ,oil system adopts integrated control ,and there is photoelectric protection.
Sheet Material Hydraulic Die Cutting Machine
Functional characteristics:Template launch deveice under the belt ,easy and flexible operation;
Electronic positioning ,precision and accurate,and the precision and accuracy cann be controlled in 0.01 to 0.03mm ,push board
back forth precision can be controlled in 0.02 to 0.05mm.
There is shockproof board installed at under-chassis ,therefore ,the machine body is stable and reliable.
Applies to punch electronic materials such as aluminum foil ,PET ,protective film through cutting or kiss cutting ,all kinds of
precision components of stamping forming.
PLC +man-machine automatic programming control ,oil system adopts integrated control ,and there is photoelectric protection.
