Module spare parts T8151B

Focus on DCS, PLC, robot control system and large servo system.

Main products: various modules / cards, controllers, touch screens, servo drivers.

Advantages: supply of imported original products, professional production parts,

Fast delivery, accurate delivery time,

The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

T8151B

Hart Two-State Output Channel Specifications Item Specifications Number of Channels 16 Isolation Each channel is optically isolated from the system and factory-tested to 1500 V DC. No channel-to-channel isolation. Nominal Signal Span On state 20 mA Off state 0 or 4 mA (configurable) Full Signal Range 0 to 24 mA Safety / Diagnostic Accuracy 5.0% of span Resolution 12 bits Compliance Voltage 20 mA into 600 Ω load Open-Loop Detection <1.0 mA – when the output drifts 15% out of the configured value Wiring diagram and terminations for 2-Wire HART two-state output channels. DeltaV SIS Logic Solver February 2021 www.emerson.com/deltavsis 9 Discrete Input Channel Specifications Item Specifications Number of Channels 16 Isolation Each channel is optically isolated from the system and factory-tested to 1500 V DC. No channel-to-channel isolation. Detection Level For On ≥2 mA Detection Level For Off ≤1.65 mA Input Impedance ~1790 Ω Input Compatibility Inputs compatible with: „ NAMUR sensors (12 V) „ Dry contact „ Dry contact with end-of-line resistance Line Fault Detection – Short Circuit (Optional) 100 Ω > 6 mA Line Fault Detection – Open Circuit (Optional) > 40 kΩ <0.35 mA Line Fault Detection — The Discrete Input channels have line fault detection for detecting open or short circuits in field wiring. To use this capability you must: Enable line fault detection in your configuration. Enable line fault detection on a channel-by-channel basis when you configure the channels. Connect the dry contact to external resistors. Connect the dry contact to a 12 KΩ resistor in parallel (allows the open circuit detection) and a 2.4 KΩ resistor in series (allows short circuit detection). Line Fault Detection in NAMUR Sensors — Line fault detection is built into NAMUR sensors. Do not use external resistors with NAMUR sensors; however, you must enable line fault detection in your configuration when using NAMUR sensors. Wiring diagram and terminations for d
