Hot Sale High Quality Radar Level Meter Sensor Transmitter

TEMHRD 906 Water Tank Radar Level Sensor

TEMHRD906 is a hight frequency water tank radar level sensor apply to hygienic liquid storage and corrosive container, it's small antenna size, easy to install and non-contact radar, no wear, no pollution. Almost no corrosion, bubble effect and not affected by water vapor in the atmosphere, the temperature and pressure changes.

Features

1. Application:Hygienic liquid storage,Corrosive container
2. Measuring Range:20 meters
3. Process Connection:Flange
4. Medium Temperature:-40°C ~ 150°C
5. Process Pressure:-0.1 ~ 4.0MPa
6. Accuracy:± 3mm
7. Protection Grade:IP67
8. Frequency Range:26GHz
9. Signal Output:4... 20mA/HART (Two-wire / Four)RS485/ Modbus
10. Explosion-proof Grade:Exia ⅡC T6 Ga

Characteristics

1. Small antenna size, easy to install; Non-contact radar, no wear, no pollution.
2. Almost no corrosion, bubble effect; almost not affected by water vapor in the atmosphere, the temperature and pressure changes.
3. Serious dust environment on the high level meter work has little effect.
4. A shorter wavelength, the reflection of solid surface inclination is better.
5. Beam angle is small, the energy is concentrated, can enhance the ability of echo and to avoid interference.
6. The measuring range is smaller, for a measurement will yield good results.
7. High signal-to-noise ratio, the level fluctuation state can obtain better  performance.
8. High frequency, measurement of solid and low dielectric constant of the best choice.

Principle

Radar level transmitter antenna microwave pulse is narrow, the downward transmission antenna. Microwave exposure to the medium surface is reflected back again by the antenna system receives, sends the signal to the electronic circuit automatically converted into level signals (because the microwave propagation speed, electromagnetic wave to reach the target and the reflected back to the receiver this time is almost  instantaneous).

Installation Guide

Outer Shell Size

Product Size

TMEHRD906 Model Selection

 More Selection

Packing and Shipping

Service

Company Information

Dalian Taijia Technology Co.,Ltd is a high technology company which specializes in supplying and supporting of ultrasonic measurement equipment. prime products include ultrasonic transit-time flow meter, ultrasonic level meter, ultrasonic thickness meter etc. Our products are widely used in water supply and drainage water, petroleum and chemicals, food and pharmaceutical.We have sold product in more than 30 countries, such as America. Italy. India. Korea. Germany. Canada. Australia etc.
