Taijia VM-6320 Vibration Meter,portable Vibration Analyzer Portable Vibration Analyzer

Model:

VM-6320 vibration meter

Specifications:

Acceleration 0.1-200m2/s (10Hz to 1KHz  10Hz to 10KHz )

Velocity :

0.1-200mm/s0.  (10Hz to 1KHz)

Displacement:

0.001-2.0mm(10Hz to 1KHz)

Accuracy:

<5%

Power supply:

4x1.5V  AA(UM-3)battery

Battery indicator:

low battery indicator

Dimensions :

160x68x32mm

Weight:

181g(not including battery)

Display

4 digits, 18 mm LCD

Manual power off or Auto power off

Transducer

Piezoelectric accelerometer

Parameters measured

Velocity, Acceleration, and displacement

Measuring range

Velocity

0.01-20.00 cm/s   true RMS

Acceleration

0.1-200.0m/s   equivalent peak

Displacement

0.001-2.000mm Peak - Peak value

Frequency range for measuring

Acceleration

10Hz. to 1kHz. In '1' mode

10Hz. to 10kHz. In  '10'  mode   for bearing condition check

Velocity

10Hz. to 1kHz

Displacement

10Hz. to 1kHz.

Operating conditions:

Temperature:0-+50℃, Humidity:≤90%RH
