Product Description

ZBL-U5200 Multi-channel Ultrasonic detector civil engineering equipment

Structural concrete compressive strength, crack depth and defect detection
Ultrasonic transmission method for rapid detection of pile foundation, continuous wall integrity;
Geological prospecting, rock integrity, weathering evaluation test
Rock, concrete and other non- metallic materials mechanical properties testingUltrasonic-rebound combined method for testing compressive strength of concrete
ZBL-U5200 Multi-channel Ultrasonic detector civil engineering equipment

Detailed Images

Model	ZBL-U5200 Multi-channel Ultrasonic detector civil engineering equipment
Control Mode	Built-in AB industrial control board
Monitor	5.7 inch, semi inverse semi penetration, TFT
Operating Mode	Touch screen & Keys
Data Storage	Built in electronic hard disk(≥4GB)+U disk
Acquisition Mode	Single channel manual point by point acquisition
Number of Channels	1 emitter+1 receiver
Trigger	Signal
Sampling Interval(μS)	0.025~1638.4 optional multiple levels
Acoustic Time Accuracy(μS)	0.025
Acoustic Time range(μS)	±1677700
Dynarnic Range(dB)	154
Bandwidth(kHz)	3~450
Receiving Sensitivity(μV)	≤10
Gain Accuracy(dB)	0.5
Transmitting Voltage(V)	65, 250,500,1000 optional four levels
Work time(h)	>8
Power supply	Internal:Built-in Battery
Power supply		External: 220VAC/DC
Operational Environment	Temperature(℃): -10~+50
Operational Environment		Humidity (RH) :<90%

Analyse system

ZBL-R630A Rebar scanner

ZBL-R630A is used to test the location of rebar in concrete, the thickness of the protective layer, and the diameter, orientationand distribution of rebar by using an electromagnetic induction method. It also can be used to test the distribution of magneticand conductor such as cables and metal pipes in non-magnetic medium and non-conducting medium

ZBL-R800 Multifuncational Rebar detector

ZBL-R800 is a multi-functional integrated rebar detector which can be used for testing the thickness of protective layers, measuring the diameter, location, and distribution of rebar as well as for detecting the corrosion content of a rebar.

TEM912 integrity voice report digital concrete rebound hammer

TEM912 Series DIGITAL TEST HAMMER automatically Record, Save, Calculate and Processing data.

Company Profile

Dalian Taijia Technology Co.,Ltd is a high technology company which specializes in supplying and supporting of ultrasonic measurement equipment. prime products include ultrasonic transit-time flow meter, ultrasonic level meter, ultrasonic thickness meter etc. Our products are widely used in water supply and drainage water, petroleum and chemicals, food and pharmaceutical. We have sold product in more than 30 countries, such as America. Italy. India. Korea. Germany. Canada. Australia etc. We thank you for visiting our Web Site and look forward to the opportunity of being of service to you.

Trade terms 1. 18 Month's Warranty. 2. Delivery time:3-7 working days after payments received 3. MOQ:1 set. 4. Service express company:TNT/DHL/FedEX. 5. We accept T/T, Western Union, PayPal & Secure Payment. NO.5 Shanshui Yuan, High-tech Industrial Zone Dalian, China 116033 E-mail:office at TEL:86-411-39685079 WhatsApp/WeChat:+86 15541112235 web:/
