Taijia Level Gauge Liquid Nitrogen Level Sensor Ultrasonic Level Meter

Taijia Level Gauge Liquid Nitrogen Level Sensor Ultrasonic Level Meter photo-1
Taijia Level Gauge Liquid Nitrogen Level Sensor Ultrasonic Level Meter photo-2
Taijia Level Gauge Liquid Nitrogen Level Sensor Ultrasonic Level Meter photo-3
Taijia Level Gauge Liquid Nitrogen Level Sensor Ultrasonic Level Meter photo-4
Taijia Level Gauge Liquid Nitrogen Level Sensor Ultrasonic Level Meter photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Other
Year Established:
2012
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

level gauge Liquid nitrogen level sensor

Taijia level gauge Liquid nitrogen level sensor Ultrasonic level meter

Introductions



UTG21-BE is a non-contact one and dose not directly contact liquid, so the fault rate is low. The meter’s all input and output lines must be with such protection functions as lightning protection and short circuit prevention.



Technical Parameter

Model

UTG21-BE ultrasonic level meter

Range

0~20m

Blind area

0.2m~0.8m

Accuracy

0.3%

Pressure

Less than four atmospheric pressure

Display

LCD display built-level height or distance

Digital output

RS485 Interface, ModBUS agreement or custom

Analog Output

4-20Ma

Supply voltage

four-wire DC24V 120mA

Protection grade

IP67

Proof-explosion grade

EX dll BT4

Installation

Flange

Shell material

Aluminum Die Casting,proof-explosion shell

Ambient temperature

-20℃~+60℃





Taijia level gauge Liquid nitrogen level sensor Ultrasonic level meter

Taijia level gauge Liquid nitrogen level sensor Ultrasonic level meter

Taijia level gauge Liquid nitrogen level sensor Ultrasonic level meter

Taijia level gauge Liquid nitrogen level sensor Ultrasonic level meter

Taijia level gauge Liquid nitrogen level sensor Ultrasonic level meter



Recommandation

Taijia level gauge Liquid nitrogen level sensor Ultrasonic level meter Taijia level gauge Liquid nitrogen level sensor Ultrasonic level meter Taijia level gauge Liquid nitrogen level sensor Ultrasonic level meter Taijia level gauge Liquid nitrogen level sensor Ultrasonic level meter
Company Information

Dalian Taijia Technology Co.,Ltd is a high technology company which specializes in supplying and supporting of ultrasonic measurement equipment. prime products include ultrasonic transit-time flow meter, ultrasonic level meter, ultrasonic thickness meter etc. Our products are widely used in water supply and drainage water, petroleum and chemicals, food and pharmaceutical.

We have sold product in more than 30 countries, such as America. Italy. India. Korea. Germany. Canada. Australia etc.

We thank you for visiting our Web Site and look forward to the opportunity of being of service to you.
