Home > Instruments & Meters > Test Instrument > Test Machine > China Motar Concrete Test Hammer Rebound Test Hammer Sclerometer
China Motar Concrete Test Hammer Rebound Test Hammer Sclerometer
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
2017
Annual Export Value:
US$10 Million - US$50 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
R800 Integrated Rebar Deep Scanner Steel Bar Diameter Detector Concrete CovermeterNegotiableMOQ: 1 -
Rebar Detection Detector Rebar Scanner Reinforced Concrete Rebar Scanner DistributionNegotiableMOQ: 1
-
Zc3a Manual Sclerometer Rebound Hammer for Concrete Testing EquipmentNegotiableMOQ: 1
-
China Steel Bar Rebar Locator Detector Concrete Cover MeterNegotiableMOQ: 1
-
China Concrete Sclerometer/Concrete Rebound Test HammerNegotiableMOQ: 1
ZC3-A concrete rebound hammer
Usage Overview
ZC3-A concrete rebound hammer is applied to test the compressive strength of hardend concrete in building structure.
Standard:JGJ/T23-2011; GB /T9138-1988; JJG817-93; ASTM C 805; BS 1881:202; NF P18-417; DIN 1048; UNI 9189
Product name |
ZC3-A Concrete Test Hammer |
Standard Impact energy |
2.207J |
Testing Range |
10~60Mpa |
Stroke of rebound hammer |
75±0.3mm |
Average rebound value |
80±2 |
The static friction of pointer slider |
0.65N±0.15N |
Sphere radius of rebound pole SR |
25±1mm |
Working Humidity |
≤90%RH |
Working Temperature |
-10℃~+50℃ |
Size |
195x140x45mm |
Weight |
2.1KG |
Detailed Images
1) Center rod is made from imported material, high accuracy and durable resistance.
2) The shell is made from high Aluminum or high polymer material in order to perfect protect instrument from damage and extend use life.
3) Pointer slider is outside structure, its friction can be balance well and easy to be adjusted so that we can make sure that the instrument is accurate.
Company Profile
Cangzhou Lovely Technology Co.,Ltd
Cangzhou Lovely Technology Co.,Ltd. is a growing company with over 12 years of experience in China, is the leading manufacturer and supplier of testing equipment used for evaluating construction and civil engineering materials. We design and manufacture all machines and accessories either by our self or in close cooperation with long-term partners.
Our equipment is used throughout the world for testing soil, concrete, cement, asphalt and aggregate materials. This testing involves evaluations of materials, which are used in construction projects ranging from roads, bridges and tunnels to dams, earthworks, airports, railways, etc.
· All our products are made in China .Excellent quality with competitive price
Packing & Delivery
· Tianjin port or Qingdao Port deliver by sea and Also can ship by air via express company
our customer
FAQ
Q1:Are you a factory or trading company?
A:We are a factory specializing in testing equipment used for evaluating construction and civil engineering materials. We also deal with various related equipment based on customer's requirement.
Q2:Where is the nearest loading port?
A:Qingdao port or Tianjin port.
Q3:What’s the MOQ of the product? A: One set.
Q4:Did your factory pass the ISO 9001? A: YES.
Q5:How long is the production cycle after ordering?
A:Based on the order. Generally it is about 3-10 days.
Q6:What is the payment method?
A:T/T payment, West Union, L/C payment ect.
Q7: Do you support customizing service?
A: Yes, we could customize the out package, machine's color, Logo and Voltage as request. With more than 12 years' production experience. We would give you an excellent experience!
