2000kn Manual Brick Compressive Strength Testing Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
2017
Annual Export Value:
US$10 Million - US$50 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Concrete Testing Equipment and Machinery Press Test Machine for ConcreteNegotiableMOQ: 1 -
2000KN Digital Concrete Compression Machine PriceNegotiableMOQ: 1
-
Digital Concrete Compression Machine 2000KNNegotiableMOQ: 1
-
Concrete Cube Compression Testing MachineNegotiableMOQ: 1
-
Compression Force Display Panel Compression Load MonitorNegotiableMOQ: 1
DYE-2000 Digital Compression Testing Machine
Product Details
Product Application
1. DYE-2000 electro-hydraulic pressure testing machine is driven by hydraulic power source, and intelligent measurement and control instrument is used to collect and process test data. It is composed of four parts: test host, oil source (hydraulic power source), measurement and control system and test apparatus. The maximum test force is 1000kN, and the accuracy level of the testing machine is better than level 1.
2. DYE-2000 electro-hydraulic pressure testing machine can meet the national standard test requirements for brick, concrete, cement and other materials. Manual loading and digital display of loading force value and loading speed value.
3. The testing machine is the main engine oil source integrated structure;It is suitable for compressive test of cement and concrete. With appropriate fixture and measuring device, it can meet splitting test, bending test and static compressive elastic modulus test of concrete.
2. DYE-2000 electro-hydraulic pressure testing machine can meet the national standard test requirements for brick, concrete, cement and other materials. Manual loading and digital display of loading force value and loading speed value.
3. The testing machine is the main engine oil source integrated structure;It is suitable for compressive test of cement and concrete. With appropriate fixture and measuring device, it can meet splitting test, bending test and static compressive elastic modulus test of concrete.
Model | DYE-2000A |
Name | Manual screw digital display compression testing machine |
Maximum test force (KN) | 2000 |
Test accuracy | Level 1 |
Space adjustment method | Manual screw adjustment |
Press space(mm) | 320 |
Sensor type | Oil pressure |
Upper platen size (mm) | 240x240 |
Lower platen size (mm) | 240x240 |
Motor powder (KW) | 0.75 |
Mainframe dimensions(mm) | 900x400x1250 |
Machine weight(kg) | 600 |
Detailed Images
Protective net is more safe
Test results are automatic processing, storing and printing.
Built in radial piston oil pump,stable output and low noise
