Improved Portable Road Markings Retro-reflectivity Tester
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
2017
Annual Export Value:
US$10 Million - US$50 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Manual Test Hammer Concrete Test Hammer Rebound Test HammerNegotiableMOQ: 1 -
Digital Concrete Rebound | Test Hammer HT225NegotiableMOQ: 1
-
Ht225 Digital Concrete Rebound Hammer Tester ResiliometerNegotiableMOQ: 1
-
High Quality Wholesale Concrete Crack Depth Detector Gauge PriceNegotiableMOQ: 1
-
Integrated Steel Rebar Scanner Locator Concrete Cover Thickness TesterNegotiableMOQ: 1
LA-6116 Rainy Night Marking Reflectance Coefficient Measuring Instrument
Usage Overview
LA-6116 Rainy Night Marking Line Retroreflective Measuring Instrument.
The upgraded version of our company on the original marking line is an open optical path portable field measuring instrument which is used to measure the retroreflective brightness coefficient of the marking line. The unit is mcd · m-2 · lx-1.
The main characteristics of its research: it simulates the motor vehicle driving on the road at night, the headlights illuminate the road (made of retro-reflective materials), and after being reflected, the brightness observed by the driver in the cab. It measures the nighttime retroreflective brightness coefficient, or RL value.
Measurement item |
retroreflective brightness coefficient mcd.m-2.lx-1 |
Measurement range |
0-4000 |
Observation angle |
1.05 ° |
Incidence angle |
88.76 °, complementary angle is 1.24 ° |
Color temperature of light source |
2856 ± 50K |
Measurement aperture area |
200mm x 95mm |
Repeatability measurement error |
≤2% |
Continuous working time of battery |
> 30h |
Data storage space |
8GB |
Built-in battery capacity |
12V / 13Ah |
Charging power supply |
DC 15V |
Working environment temperature |
-15 ℃ ~ + 60 ℃ |
Ambient humidity |
<98%, no frost |
Volume of the whole machine |
360mm x 135mm x 173mm |
Detailed Images
1. Open optical path design, support measurement under dry, humid and continuous rainfall conditions;
2. Quick measurement (reverse reflection brightness coefficient value measured within 1.5 seconds);
3. Simple calibration procedure; calibration system in line with international standards
4. Long standby time, and supports fast charging;
2. Quick measurement (reverse reflection brightness coefficient value measured within 1.5 seconds);
3. Simple calibration procedure; calibration system in line with international standards
4. Long standby time, and supports fast charging;
5. 5 inches sunlight screen, the operation interface can be seen clearly under the light;
6. Support to store more than 100,000 pieces of detection data, including measurement data, operator, road information, GPS information and detection time, etc.
7. USB data interface, test report is exported to computer in the form of database
8. Real-time voice broadcast of measurement data;
9. Bluetooth printer prints out the test results on site;
10. Touch the keyboard to input Chinese characters, English and characters;
11. Real-time sampling and real-time display of on-site temperature and humidity;
12. It is exquisite, small and light.
8. Real-time voice broadcast of measurement data;
9. Bluetooth printer prints out the test results on site;
10. Touch the keyboard to input Chinese characters, English and characters;
11. Real-time sampling and real-time display of on-site temperature and humidity;
12. It is exquisite, small and light.
Company Profile
Cangzhou Lovely Technology Co.,Ltd
` Cangzhou Lovely Technology Co.,Ltd. is a growing company with over 12 years of experience in China, is the leading manufacturer and supplier of testing equipment used for evaluating construction and civil engineering materials. We design and manufacture all machines and accessories either by our self or in close cooperation with long-term partners.
Our equipment is used throughout the world for testing soil, concrete, cement, asphalt and aggregate materials. This testing involves evaluations of materials, which are used in construction projects ranging from roads, bridges and tunnels to dams, earthworks, airports, railways, etc.
· All our products are made in China .Excellent quality with competitive price
Our Advantages
1. Get our in-time reply via email or telephone or instant messenge. Our product specialist will guide you find the suitable product according to your requirement;
2. Get best product with excellent quality and competitive price;
3. One year guarantee for whole machine and in time technical support by video or email. Always enjoy our considerable & full-side after-sales service;
4. Feeling very convenient since we can help you source and ship products from different factories via one shipment, which is significant to save your time and cost;
5. Easily make the payment via West Union, Paypal, Credit Card for small value order;
Any questions, please contact me without hestitation, welcome your inquiry!Price can be negotiated.
Packing & Delivery
· Tianjin port or Qingdao Port deliver by sea and Also can ship by air via express company.
FAQ
Q1: How long is the lead time?
A: Normally 3-7 days. Depend on the order quantity.
Q2: What is the transportation method?
A: By Express, By air or By Sea.
Q3: What are the payment terms?
A: Credit card ,Bank Wire Transfer, L/C, Western Union etc.
Q4: How is the after-sales service?
A: 12 months quality warranty with online technical support.
Q5: Are there any factory quality certificates?
A: We have the ISO certificate and National patent certificates.
Q6: Is Lovely test trustworthy?
With more than 12 years' production experience. We would give you an excellent experience!
